European Standard Quality Sun Powered Water Heaters(Solar Heaters)

FOB Price

US$ 500 - 3,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Evacuated Tube	Pressure	Pressurized
Circulation Type	Indirect / Closed Loop (Active)	Heating System	Thermosyphon (Passive)
Connection Type	Split	Installation	Freestanding
Certification	CE, Other, CE, Solar Keymark,SRCC	Capacity	150
Place of Origin	Zhejiang, China	Brand Name	Inlight or OEM

Yinuo solar water heaters can be used in extreme cold area,Ukraine, Russia,UK,Sweden etc.
from 100L to 1000L all are available.

Haining Yinuo electric Co., Ltd manufactures and supplies all kinds of solar water heaters, solar collectors.

Our professional group will design the best solar heating system solutions for your domestic house, hotel, hospital or industry plants.

European Standard Quality Sun Powered Water Heaters(Solar Heaters)
1. Solar Water Heater Storage Tank Capacity: 80L,100L,120L,150L,200L,250L,300L,400L,500L,600L,700L,800L,1000L,1200L
2. Heat Collecting Type: Glass evacuated tube solar collector
3. Inner Storage Tank Material: Food-grade stainless steel SUS304-2B or SUS316 1.0mm - 2.0 MM or enamel inner tank
4. Tank Exterior Shell Material: High-quality white coated color steel or stainless steel 0.4MM
5. Heat Insulation: High-density polyurethane integrated foam-forming layer with 72~80 hours heat preservation
6. Thickness of Insulation Layer: 50mm, 55mm, 60mm
7. Coils in tank as heat exchanger in tank: Stainless steel, or copper coils
8. Quantity of coils in tank:1 roll,2 rolls,3 rolls or four rolls
9. Vacuum Tube Model: Φ47/1500mm, Φ47/1800mm, Φ58/1800mm
10. Vacuum Tube Material: Borosilicate glass 3.3
11. Vacuum Tube Absorbing Coating: Single or tripple target magnetron sputtering AL/AL-ALN or Cu-SS-ALN/AIN
12. Bracket: Hot-dip galvanized steel,stainless steel or aluminum alloy
13. Angle of bracket: 10°-50°, universal bracket suitable for slope and flat roof installation
14. Accessories: Stainless bolts & nuts, anti-aging silicon gasket, dustproof rubber seal, plastic air-vent cap
15. Hot Water Output:45-95°C
16. Designed Pressure:6 Bar
