MC-DU-10 Cheapest 10.4 inch Portable Color Doppler Full Digital Ultrasound Machine

Full Digital Color Doppler Ultrasound scanner

Model: MC-DU-10

Standard configuration:

Main unit:1 pc Double probe sockets, automatically identify probe;

3.5MHzmulti-frequency abdomen convex probe

6.5MHz multi-frequency trans-vaginal probe

7.5MHz multi-frequency high linear probe

Optional configuration:

Trolley

Video recorder (P93W-S)

Laser printer (Specified models: HP Laser Jet 1020,

HP Laser Jet 1022, HP Laser Jet P1007,

HP Laser Jet P1008)

Battery: RYLB-02

General Specification

2.1  Dimension

400 mm (L)´186mm (W)´ 385mm (H)

N.W.: 8.8 Kg(without probe)

2.2  Power Supply

Dual power supply: AC110/230 -15%~+10%,60/50Hz±1Hz

Battery: large capacity(6.6Ah)Li-battery 1 PC,120 minutes life work.

2.3  Display

10.4" high definition & flicker free color medical LCD monitor

System Description

3.1  Probe specification

3.5MHz R60 broadband convex

Scanning angle: 60°

elements: 80

frequency scope: 2.0MHz-5.0MHz

4 multi-frequency:2.0/2.5/3.5/5.0

Max scanning depth≥190mm

Blind zone: ≤5mm

resolution: axial resolution ≤1mm,lateral resolution≤2mm

precision of geometric location: lateral≤5%,vertical≤5%

7.5MHz L40 broadband linear

element: 80

frequency scope: 6.0MHz-9.0MHz

4 multi-frequency: 6.0/6.5/7.5/9.0

Max scanning depth≥60mm

Blind zone: ≤3mm

resolution: axial resolution ≤1mm,lateral resolution≤1mm

precision of geometric location: lateral≤5%,vertical≤5%

6.5MHz R11 broadband

Scanning angle: 135°

element: 80

frequency scope: 4.5MHz-9.0MHz

4 multi-frequency: 4.5/5.5/6.5/7.5

Max scanning depth≥60mm

Blind zone: ≤4mm

resolution: axial resolution ≤1mm,lateral resolution≤1mm

precision of geometric location: Product Standard shows:lateral≤10%,vertical≤5%

3.2  Operating mode

B, B/B, 4B mode

M, B/M mode

CFM

PDI

PW

THI

3.3  Probe socket: 2

3.4  Media & peripheral device

USB flash card

Video printer: UP-897MD

Color laser printer (defined model: HP Color LaserJet CP1515n,

HP Color LaserJet CP1525n)

TV Output: PAL / NTSC

3.5  Storage

Image storage, cine loop storage, cine loop ≥300 frames, 16G hard disk storage

3.6  Puncture Guide Line

Adjustable angle and memory storage

3.7  Languages

Menu operation: Chinese / English / Russia / Portuguese

4. System Application

MC-DU10 full digital color Doppler ultrasound scanner is available for the diagnosis of abdomen (including GYN and OB), cardiology, vessel and small parts, with the following scanning mode: 2D, CFM, PDI, PW and M to provide the best resolution and sensitivity.

Support convex probe, linear probe and transvaginal probe, etc.
