10.2 Inch Fetal Monitor | Guangzhou Fetal Monitor Equipments

10.2  inch Fetal Monitor | Guangzhou Fetal Monitor Equipment
Model: MC-FM120

Fetal heart rate (FHR) measurement
Measuring method                      Ultrasound Doppler
Measuring scope                        50~240BPM
Measuring tolerance                     Less than ±1BPM
Fetal heart rate curve scope               50~240BPM
Fetal heart rate numeric display scope       50~240BPM
Ultrasound working frequency             2.0MHz ,2.5MHz
Ultrasound output intensity               < 5mW/cm2

Uterine contraction pressure (TOCO) measurement
Measuring method                       External measuring
Measuring scope                        0~100 unit
Uterine contraction pressure curve scope     0~100 unit
Uterine contraction pressure numeric display scope   0~100 unit
Non-linearity tolerance                    Less than ±10%
Auto-zero function                       Yes

Fetal movement record       Manual control button label, Auto fetal movement identification
Display                     10.2”color TFT-LCD (800RGB*480)
Event mark                  9 available
Record mode                 Thermal array printer
Record paper                112mm×100mm folded thermal printing paper
Paper feeding speed           1,2,3cm/min 3 options
Fetal heart rate audible and visual alarm   Low limit 120BPM, up limit 160BPM
Alarm trigger time                      <3s
Printer failure alarm                    Paper empty alarm
Output volume                         2~3W speaker ,volume adjustable
Power Supply        AC: 100-240V,50/60Hz±1 Hz ,40VA
DC: 14.4V/2000mAh, rechargeable Li-ion battery, continuous work>4h
Safety level                          Class I, type B
Size                                 L296 mm xW312 mm xH92 mm
Net-working Capacity                 Yes

1.10.2” inch large-screen color TFT display, digital display and waveform oscilloscope of twins heart rate (FHR) and uterine constriction pressure (TOCO) value.
2.Independent user friendly interface with menu function setting. Unique rotary button control design, portable and convenient of use.
3.Self-defination of multi-event marks.
4.Directly viewing 1:1 scale of display and print-out waveform.
5.Folding thermal array printer with high resolution, easy paper loading, paper empty auto detection and printing head over-heating protection
6.7-wafer impulse ultrasound transducer, configured with special HR self correlation reading algorithm to ensure correct and reliable fetal heart rate (FHR) measurement.
7.Highly sensitive, wide scope pressure transducer ensures to achieve effective measurement of uterine contraction pressure (TOCO).
8.Fetal movement auto detection.
9.Signal intensity indication ensures effective transducer position.
10.Auto power failure protection and reliable rechargeable Li-ion battery can realize continual monitoring function.
11.Net-working capacity, convenient and ease-of –use. Convenient for hospital informatization .management and for data analysis of fetal central monitor system.
12.Meets the standard IEC60601-1,1988, class I,type B with special protection from electroshock, safe and reliable in use.
