Non-pressure Solar collector(W180)

FOB Price

US$ 100 - 350 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Evacuated Tube	Pressure	Unpressurized
Circulation Type	Direct / Open Loop (Active)	Heating System	Thermosyphon (Passive)
Connection Type	Direct-Plug	Installation	Wall Mounted
Housing Material	Stainless Steel	Certification	CE, Other, CE, solar keymark,en12975
Place of Origin	Jiangsu, China	Brand Name	Wankang
Model Number	W180

Product Description

Features:

This type uses the all-glass evacuated solar collector tubes as the heat-absorbing element. The high vacuum degree of the clearance between the outer and inner tubes reduces the heat emission which is caused by convection and conduction. The layers films (Coating) of the all glass evacuated tubes transfer the sun energy into heat energy. Depending on the different density between hot water and cold water, a water flowing cycle is created in the tube. Hot water flows automatically upwards while the cold water flows down. The water in the storage tank will be heated from this natural circulation

Material of inner tank:	SUS 304 2B(food grade) with 0.4mm thickness
Material of outer tank:	glvanized steel with 0.4mm thickness
Material of Stand part:	Aluminum alloy with 1.6mm thickness
Insolation:	plyurethane foam thickness:55-60mm
Rubber seals and rubber ring material:	Silicone Rubber
Vacuum tube	¢47/1500, ¢58/1800
Heat Preservation ability:	72Hours
Hailstone resistance:	Dia≤25mm
Optional installation angle	20C,30C,38C,45C
