Home > Products > Heat pipe solar collector > super metal heat pipe solar collector
super metal heat pipe solar collector
- shanghai
- T/T
You May Like
Product Details
| Type | Evacuated Tube | Pressure | Unpressurized | |
| Circulation Type | Direct / Open Loop (Active) | Heating System | Thermosyphon (Passive) | |
| Connection Type | Direct-Plug | Installation | Freestanding | |
| Housing Material | Stainless Steel | Certification | CE | |
| Place of Origin | Jiangsu, China | Brand Name | wankangsolar | |
| Model Number | WCD-CF |
Product Description
Specifications
solar water heater (AKII Series) mostly for domestic home use. work at non-pressure enviroment. more strong fame than AK series.Manifold material and thickness | aluminum alloy-2.0mm/ Stainless steel 304 2B- 0.8mm |
Header pipe material and thickness | Diameter:32mm, thickness 1.0mm copper pipe |
Heat pipe material and thickness | Diameter:14mm, thickness 0.5mm copper pipe |
Insulation | Polyurethane foam 50mm or Rock wool |
Test pressure and work pressure | Test pressure 9Bar, work pressure 6bar to 8bar |
Frame material and thickness | Aluminum alloy-2.0mm/ Stainless steel-1.2mm |
Collector mounting | Flat roof/slope roof |
Inlet and outlet | 1/2’’ OR 3/4’’ |
Hail resistance: | 25mm |
Coating of vacuum tube: | QB-AL-SS/CU-70/1700 or 70/1900 |
