Home > Products > Die Cutting Machine > Mylar Die Cutting (Max 300mm*300mm)
Mylar Die Cutting (Max 300mm*300mm)
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Die-cutting Machine | |
| Computerized | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | Chuanri | Model Number | MQ-320BIV | |
| Voltage | 220V 50Hz | Power(W) | 2.2kw | |
| Dimension(L*W*H) | 2750*1250*1400mm | Weight | 1000kg | |
| Certification | CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Mylar Die Cutting (Max 300mm*300mm)
Main Parameters:
Model | 320BIV |
Max Feeding Width ( mm ) | 320 |
Cutting Area ( mm ) | 300*300 |
Cutting Speed ( T/M ) | 30-170 |
Position Accuracy ( mm ) | ±0.10 |
Main Engine Power ( KW ) | 2.2 |
Size ( mm ) | 2750*1250*1400 |
Rewinding Diameter ( mm ) | 500 |
Voltage ( V ) | 220 |
Functional characteristics:
This machine is of platen pressing structure, computer servo system sheet drawing, and the two edges and vertical sides of the materials are tracked and located by the photoelectric eye. Feeding-waste draining-slitting or rolling, all of them are completed by the computer control by one turn.
Scope applicable:
The die cutting of sheet self-adhesive trademark, terylene film trademark, and the radium anti-fake trademark. This machine is the optimal assembled equipment for full cycle high-speed web-fed trademark printing machine, flexible edition printing machine, continuous screen printing machine, gravure printing machine and anti-fake trademark swaging hammer, and also the optimal machine model of a variety of trademark printing plants. It is also applicable to the die cutting and forming of the electronic industry, and tape goods production industry.
Unwinding and through die cutting the paper from roll:
