DZ20Y 250A 3P MOLDED CASE CIRCUIT BREAKER(MCCB) OEM PROVIDE
- NINGBO/SHANGHAI
- T/T
You May Like
-
DZ20 Various Type MOLDED CASE CIRCUIT BREAKER(MCCB) OEM PROVIDE
-
Series DZ15LE RESIDUAL CURRENT MODLE CASE CIECUIT BREAKER (MCCB) TRANSPARENT
-
Series DZ15LE MCCB CIRCUIT BREAKER TYPES OF ELECTRICAL SWICHES
-
DZ15LE 100A 4P MODLED CASE CIRCUIT BREAKER
-
Reversing Switch,transfer switch,rocker switch HY2 On-Off change-over switch
-
HY2 SERIES REVERSING SWITCH
Product Details
| Place of Origin | Zhejiang, China | Brand Name | LIBAJI | |
| Model Number | DZ20L | Type | Moulded Case | |
| Poles Number | 3 |
Product Description
Specifications
DZ20Y CIRCUIT BREAKERGOOD QUALITY AND REASONABLE PRICE
OEM,MANUFACTURER
IEC60947-2,CCC
EASY INSTALLATION
DZ20Y 250A 3P MOLDED CASE CIRCUIT BREAKER(MCCB) OEM PROVIDE
DZ20L series molded case circuit breaker (hereinafter referred to as circuit breaker) is suitable for circuit of AC 50Hz , rated insulation voltage 660V, rated working voltage 380V (400V) or below and rated current from 16A to 1250A. The circuit breakers take the role of infrequent turn-on or turn-off and infrequent motor start-up. The breakers have over-load, short-circuit and under-voltage protection performances so to protect the circuit and power appliance from damage. The breaker could be installed vertically(upright) or horizontally(transverse). The breaker could not be wired adversely,1,3 and 5 can only be connected with power line,2,4 and 6 con only be connected with load line.
MAIN TECHINCAL DATA
| TYPE | ln(A) RATED CURRENT | RATED WORKING VOLTAGE | lcukA RATED ULTIMATE SHORT-CIRCUIT BREAKING CAPABILITY | LΔmkA RATED RESIDUAL MAKING AND BREAKING CAPABLITY | mm FLASHOVER DISTANCE | lΔnmA RATED RESIDUAL ACTION CURRENT | lΔnmA RATED RESIDUAL NON- ACTION CURRENT | S MAX BREAKING TIMES | ||||||
| ORDINARY TYPE | TIME DELAY TYPE | |||||||||||||
| lΔn | 2lΔn | 5lΔn | lΔn | 2lΔn | 5lΔn | 10lΔn | ||||||||
| DZ20L-160 | 50,63,80, 100,125,160 | 380 | 12 | 63 | ≤60 | 50 100 200 | 25 50 100 | ≤0.2 | ≤0.1 | ≤0.04 |
≤0.5 ≤0.7 |
≤0.3 ≤0.5 |
≤0.25 ≤0.45 | ≤0.25 ≤0.45 |
| DZ20L-250 | 125,160,180, 200,225,250 | 15 | 4 | |||||||||||
| DZ20L-400 | 200,250,315, 350,400 | 20 | 5 | ≤80 ≤100 | 100 200 500 | 50 100 250 | ≤1.25 | ≤1 | ≤0.95 | ≤0.95 | ||||
| DZ20L-630 | 315,350,400, 500,630 | 30 | 6 | |||||||||||
| TYPE | TEST CURRENT FOR DISTRIBUTION PROTECTION | TEST CURRENT FOR MOTOR PROTECTION | ACCURACY OF SETTING VALUE | CONVENTIONAL TIME | INTIAP STATE |
| DZ20L-160 | 10ln | 12ln | ±20% | <0.2 TRIP | COLD STATE |
| DZ20L-250 | |||||
| DZ20L-400 | |||||
| DZ20L-630 | - |
OUTLINE AND INSTALLATION SIZE
