Electronic Jacquard-ZJGES

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1.The new type balance-arm lifting mechanism
2.Can work in high speed
3.Super capacity of datas
4.Energy saving

Model	ZJ-GES/GE
Main Features
Field of Application	Rapier, Waterjet, Airjet and also Shuttle Loom
Fabric Suitability	All flat fabrics and terry cloth including home textile, garment fabrics, towel, tie, label and so on.
Specification of Jacquard	1920hook (10 line, 24 pcs of each line) 3840hook (20 line, 24 pcs of each line) 5760hook (30 line, 24 pcs of each line) 7680hook (40 line, 24 pcs of each line) 9600hook (50 line, 24 pcs of each line)
Drive System and Shedding	Double lift, full shedding, easy, accurat shed opening adjustment
Max Speed	650 RPM
Shedding Size	50-120mm
Type of Reversing	Spring Reversing

Features of Mechanical Parts

Driven by extremely solid bilateral eccentric cam;
Min maintance
With integrated frame design bearing advantages of high precision, high intensity and light weight;
equipped with the balance-arm lifting mechanism which eliminates unbalanced load and can work without vibration;
adopting the simple knife height-adjustment method and the fast opening dimension-adjustment system which bring extreme flexibility to the machine.
Equipped with the solid lifting mechanism, supporting structure and the needle-selecting system which can work normally in high speed.

Controller Profile

Plastic Board Profile
