Slim ITX APU E450 motherboard integrated HD6320 MSATA WIFI HDMI
USD $1 - $2
/ Piece
1 Piece(Min.Order)
- ShenZhen
- Credit Card PayPal
You May Like
-
MINIX D2700-HD Dual Gigabit LAN with DC support HDMI VGA d2700
-
d2500CC dual Gigabit Ethernet intel d2500cc support wayos soft Road motherboard ITX dual network motherboard
-
D2550 DC fanless ATOM D2550 Dual NIC HD HTPC
-
Atom 3.5 inch D525 Car PC Atom D525 the industrial tablet D525 motherboard POS medical
-
motherboard d525 multi NIC NIC the soft route motherboard wayos sea spiders ITX other 6 NIC
-
Intel D2800MT ITX wide voltage input lvds hdmi ITX dn2800mt fanless
Product Details
| Products Status | Stock | Application | Desktop | |
| Model Number | E450 | Place of Origin | Guangdong, China |
Product Description
Specifications
Slim ITX APU E450 motherboard integrated HD6320 MSATA WIFI HDMISlim ITX APU E450 motherboard integrated HD6320 MSATA WIFI HDMI
Motherboard characteristics
1 AMD the latest APU motherboard, integrated super HD6320 graphics card, support 1080P
2 motherboard integrated 12V DC DC power, integrated AMD dual-core 1.65G CPU
3 support for third-generation memory latest MINI-SSD solid state drive, the HDMI, WIFI, 3G.
AMD the E450 1.6/1.65GHz dual-core processor
Chipset AMD Hudson D1 chipset
Graphics integrated AMD Radeon HD6320 graphics core
Memory 1 * 204-pin dual-channel DDR3 1333/800/667 memory, maximum support 4G
Expansion slot The 2 * PCIEx1 slot wireless WIFI and MSATA of interface, which can be accessed
Storage function * rial ATA2 3Gb / s controller (a with MSATA Total column)
Realtek ALC662 6-channel audio features hi-fi audio
The network functions 1 * RTL8111E trillion NIC supports Wake on LAN
Backplane I / O interfaces, 1 * HDMI Interface
1 * VGA Interface (HDMI interface with asynchronous display)
2 * USB 2.0 interface (supports 4 USB devices)
1 * RJ-45 cable interface
1 * Audio I / O interface (Line Out) green interface 1 * Audio I / O interface (Mic red interface)
1 * 12V DC_JACK input
Built-in I / O interface 3 * USB 2.0 interface (supports the six USB device)
1 * 4p power seat (do 12V power input and output interface)
2 * fan connectors
2 * RS232 connector
1 * VGA 2 * 5 interface
2 * 15 LVDS interface (24BIT LVDS interface support dual-channel) (optional)
1 * Audio I / O interface (Line Out) green interface
1 * Audio I / O interface (Mic red interface)
BIOS AMI 16 DPI Flash ROM
Product Size Mini ITX Form Factor (17cmx17cm
