Item

Rating

Note

Capacity

Typical

3000mAh

Discharge:0.2CmA

cut off Voltage:2.75V

Nominal(Minimum)

3000mAh

Nominal   Voltage

3.7V

Discharge:0.2CmA

cut off Voltage:2.75V

AC   Impedance Resistance

≤170mΩ

Discharge   Cut-off Voltage

2.75V

Charge   Current

0.5C mA

Standard Charge

Max. Charge   Current

1.0C mA

Charge Voltage

4.2V

Max. Charge   Voltage

4.23V

Charge Time

Approx 3.0h

Standard Charge

Fast Charge   Time

Approx 2.0h

1.0CmA

Standard Discharge Current

0.5C mA

Standard Discharge

Max.   Discharge Current

2.0C mA

Weight

Approx 33 g

Operating   Temperature

Charge

0~+45°C

Discharge

-20~+60°C

Storage Temperature

less than 1 month

-20~+45°C

Recommended storage temperature: 25°C,at the shipment state

less than 6 months

-20~+35°C

Item

Test Condition

Over charge protection

The battery should be charged under 5.0V/1C. The charging should be shut off   when the voltage of internal cell becomes more than the specified protection   voltage.

Over discharge protection

The battery should be discharged with 1 C/mA. The discharging should be shut   off when the voltage of internal cell becomes less than the specified   protection voltage.

Short protection

After rated charge, (+) and (-) terminals are connected   with 10mΩ mental resistor or equivalence.

Current consumption

Ordinary current consumption: consumption current   of the protection circuit when internal cell voltage reaches 3.7V(Max:6μA)

Discharge   Temperature

-20°C(0.2C)

25°C(0.5C)

60°C(0.5C)

Discharge   Capacity

>60%

100%

>90%

Discharge Current

0.2C

0.5C

1.0C

2.0C

Discharge Capacity

>100%

100%

>97%

>90%
