high efficient YQLX series air oil seperator filter element

FOB Price

USD $10 - $200 / Piece

1 Piece(Min.Order)

Port qingdao shanghai and other China's port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Suction Filter	Structure	Cartridge
Place of Origin	Henan, China	Brand Name	dakang
Model Number	YQLX series

Product Description

Specifications

air oil seperator
1.in rotary air compressor and vacuum pump
2.high efficiency filtration separation
3.ISO 9001-2008

As air oil separator filter in rotary air compressor and vacuum pump, due to the compressed air separation, condenses oil vapor. YQLX series filter adopts high superfine fiber agglomerate anti-corrosion materials as filtration, advance by filter layer, superfine fiber layer, support layer and layer and layer, etc, to ensure settlement of large oil can be separated directly, tiny oil gas dissolved in through the filter was disintegrated into the oil droplets greatly condenses and exclusion. With high efficiency filtration separation (after no more than oil gas 3mg/m3), the initial pressure.

Model	Flowing (m3/min)	Residual oil(mg/m3)	Initial pressure differential	Working Pressure (MPa)	Working Temperature(°C)	Size (mm)				MANN corresponding model
Model	Flowing (m3/min)	Residual oil(mg/m3)	Initial pressure differential	Working Pressure (MPa)	Working Temperature(°C)	D	D1	D2	L	MANN corresponding model
YQLXII-3.5	3.5	3	0.02	0.7	120	φ220	φ75	φ135	160	49 301 52 121
YQLXII-4.5	4.5					φ170	φ75	φ135	200	49 301 52 131
YQLXII-6.5	6.5					φ200	φ109	φ170	230	49 301 52 101
YQLXII-9	9					φ200	φ109	φ170	305	49 302 52 131
YQLXII-16	16					φ355	φ220	φ300	305	49 303 52 121
YQLXII-20	20					φ328	φ209	φ275	400	49 303 52 111
YQLXII-22	22					φ355	φ220	φ300	400	49 304 50 101
YQLXII-28	28					φ355	φ220	φ300	500	49 305 52 111
YQLXII-33.5	33.5					φ335	φ220	φ300	600	49 305 52 101
YQLXII-39	39					φ355	φ220	φ300	700	49 305 52 102

Model	Flowing (m3/min)	Initial pressure diffierential	Working pressure(MPa)	Working temperature(°C)	Size (mm)			MANN corresponding model
Model	Flowing (m3/min)	Initial pressure diffierential	Working pressure(MPa)	Working temperature(°C)	D	D1	L	MANN corresponding model
YQLXIII-0.1	0.1	3	0.02	120	φ30	φ10	60	49 000 52 108
YQLXIII-0.25	0.25				φ55	φ25.5	75	49 000 52 351
YQLXIII-0.4	0.4				φ72	φ32.2	80	49 000 52 352
YQLXIII-0.7	0.7				φ80	φ45.2	125	49 000 52 353
YQLXIII-0.9	0.9				φ80	φ45	145	49 000 50 611
YQLXIII-1.4	1.4				φ70	φ40	250	49 000 52 107
YQLXIII-1.8	1.8				φ70	φ40	330	49 001 52 112
