D.King Product Industry Hydraulic in Line Oil Filter
- Shanghai Qingdao Tianjin
- T/T
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | D.King | |
| Model Number | FBX, FAX, GP, TZX, QYLX, SFX, NLX, TXX series |
Product Description
Specifications
hydraulic in line oil filter1Stable and constant pressure
2Filter Precision: 1-100um
3Type:oil filter
4ISO9001-2008
Effect: Hydraulic pressure oil return filter element install oil-put of oil pump in common. use to protect oil pump avoid to suction major mechanical admixture.filtering prill what component abrade created in hydraulic pressure and sealing element rubber impurity etc pollutant , make oil what reflow to tank keep clean .
Characteristics: structure strict reasonable , big ability pass oil , small reset pressure loss , big quantity accept dirt .etc.
Structure:
top and bottom caps material : aluminum , stainless steel
inner tube material: galvanized sheet , stainless steel tube
filter medium, material :stainless steel mesh and filter paper
Applications: scope of application: petroleum, water, air, oil field, refinery, medicine equipment, pipeline filters, railroad, astronautics, project machinery, etc
Model:
Model | Latus rectum(mm) | Nominal flow rate(L/min) | Filter precision(um) | Nominal pressure(MPa) | Pressure loss | Mating assemibly model | |
Initial | Max | ||||||
TZX2-10 | 10 | 10 | 1 3 5 10 20 30 | 1.6 | 0.05 | 0.35 | Z/QU-A10 |
TZX2-25 | 15 | 25 | Z/QU-A25 | ||||
TZX2-40 | 20 | 40 | Z/QU-A40 | ||||
TZX2-63 | 25 | 63 | 0.07 | Z/QU-A63 | |||
TZX2-100 | 32 | 100 | Z/QU-A100 | ||||
TZX2-160 | 40 | 160 | 0.12 | Z/QU-A160 | |||
TZX2-250 | 50 | 250 | Z/QU-A250 | ||||
TZX2-400 | 65 | 400 | 0.15 | Z/QU-A400 | |||
TZX2-630 | 80 | 630 | Z/QU-A630 | ||||
TZX2-800 | 90 | 800 | 0.17 | Z/QU-A800 | |||
TZX2-1000 | 100 | 1000 | Z/QU-A1000 | ||||
Model | DN(mm) | Flow capacity (L/min) | Micron rating (um) | Nominal pressure (MPa) | Pressure loss(MPa) | Mating assembly model | |
Initial | Max | ||||||
FAX-25 | 15 | 25 | 1 3 5 10 20 30 | 1.6 | No more than 0.075 | 0.35 | RFA-25 |
FAX-40 | 20 | 40 | RFA-40 | ||||
FAX-63 | 25 | 63 | RFA-63 | ||||
FAX-100 | 32 | 100 | RFA-100 | ||||
FAX-160 | 40 | 160 | RFA-160 | ||||
FAX-250 | 50 | 250 | RFA-250 | ||||
FAX-400 | 65 | 400 | RFA-400 | ||||
FAX-630 | 90 | 630 | RFA-630 | ||||
FAX-800 | 90 | 800 | RFA-800 | ||||
FAX-1000 | 90 | 1000 | RFA-1000 | ||||
Model | Through diameter(mm) | Nominal flow rate (L/min) | Filter precision (um) | Nominal pressure (MPa) | Pressure loss(MPa) | Mating assembly model | |
Initial | Max | ||||||
FBX-25 | 55 | 25 | 1 3 5 10 20 30 | 1.6 | No more than 0.075 | 0.35 | RFB-25 |
FBX-40 | 40 | RFB-40 | |||||
FBX-63 | 63 | RFB-63 | |||||
FBX-100 | 100 | RFB-100 | |||||
FBX-160 | 160 | RFB-160 | |||||
FBX-250 | 80 | 250 | RFB-250 | ||||
FBX-400 | 400 | RFB-400 | |||||
FBX-630 | 630 | RFB-630 | |||||
FBX-800 | 800 | RFB-800 | |||||
FBX-1000 | 1000 | RFB-1000 | |||||
FBX-1300 | 1300 | RFB-1300 | |||||
Model | Through diameter(mm) | Nominal flow(L/min) | Filtrating precision(um) | Nominal pressure(Mpa) | Mating assembly model |
GP300*Q2 | 35 | 300 | 3 5 10 20 30 | 1.6 | GP-A300*Q2 |
GP400*Q2 | 400 | GP-A400*Q2 | |||
GP500*Q2 | 500 | GP-500*Q2 | |||
GP600*Q2 | 600 | GP-600*Q2 |
Model | DN(mm) | Nominal flow rate (L/min) | Filter precision (um) | Nominal pressure (MPa) | Pressure loss(MPa) | Mating assembly model | |
Initial | Max | ||||||
NLX-25 | 20 | 25 | 1 3 5 10 20 30
| 0.6 | No more than 0.1 | 0.35 | XNL-25-C/Y |
NLX-40 | 40 | XNL-40-C/Y | |||||
NLX-63 | 32 | 63 | XNL-63-C/Y | ||||
NLX-100 | 100 | XNL-100-C/Y | |||||
NLX-160 | 50 | 160 | XNL-160-C/Y | ||||
NLX-250 | 250 | XNL-250-C/Y | |||||
NLX-400 | 80 | 400 | XNL-400-C/Y | ||||
NLX-630 | 630 | XNL-630-C/Y | |||||
NLX-800 | 90 | 800 | XNL-800-C/Y | ||||
NLX-1000 | 1000 | XNL-100-C/Y | |||||
Model | DN(mm) | Nominal flow rate (L/min) | Filter precision (um) | Nominal pressure (MPa) | Reset pressure loss (MPa) | Original assembly model |
QYLX-63 | 15 | 63 | 3 5 10 20 30 | 1.0 | No more than 0.1 | QYL-63 |
QYLX-100 | 18 | 100 | QYL-100 | |||
QYLX-160 | 40 | 160 | QYL-160 | |||
QYLX-250 | 50 | 250 | QYL-250 | |||
QYLX-400 | 60 | 400 | QYL-400 |
Model | DN(mm) | Nominal flow rate (L/min) | Filter precision(um) | Nominal pressure (MPa) | Pressure loss(MPa) | Mating assembly model | |
Initial | Max | ||||||
SFX-60 | 25 | 60 | 1 3 5 10 20 30 | 1.6 | No more than 0.2 | 0.35 | RLF-60 |
SFX-110 | 110 | RLF-110 | |||||
SFX-160 | 40 | 160 | RLF-160 | ||||
SFX-240 | 240 | RLF-240 | |||||
SFX-330 | 50 | 330 | RLF-330 | ||||
SFX-500 | 500 | RLF-500 | |||||
SFX-660 | 80 | 660 | RLF-660 | ||||
SFX-850 | 850 | RLF-850 | |||||
SFX-950 | 100 | 950 | RLF-950 | ||||
SFX-1300 | 1300 | RLF-1300 | |||||
Model | DN(mm) | Nominal flow rate (L/min) | Filter precision (um) | Nominal pressure (MPa) | Pressure loss(MPa) | Mating assembly model | |
Initial | Max | ||||||
TXX-25 | 15 | 25 | 30 50 | 1.6 | 0.05 | 0.38 | XU-A25 |
TXX-40 | 20 | 40 | XU-A40 | ||||
TXX-63 | 25 | 63 | 0.07 | XU-A63 | |||
TXX-100 | 32 | 100 | XU-A100 | ||||
TXX-160 | 40 | 160 | 0.12 | XU-A160 | |||
TXX-250 | 80 | 250 | XU-A250 | ||||
TXX-400 | 88 | 400 | 0.18 | XU-A400 | |||
TXX-650 | 80 | 650 | XU-A650 | ||||
