Home > Products > Expanded Metal Machine > New Design Expanded Wire Mesh Welding Equipment
New Design Expanded Wire Mesh Welding Equipment
US$ 8,200 - 35,000
/ Piece
1 Piece(Min. Order)
- Tianjin
- T/T
You May Like
-
FT-E New Design Expanded Metal Wire Mesh Welding Machine
-
FT-E2000 Expanded Metal Wire Mesh Welding Machine
-
FT-E2000 Heavy Full Automatic Expanded Metal Wire Mesh Machine
-
Expanded Metal Making Machine From China Manufactory
-
High Performance Expanded Metal Machine Manufactory
-
Hot Sale!! Expanded Metal Machine Made in China
Product Details
| Place of Origin | Hebei, China | Brand Name | Feiteng | |
| Model Number | Feiteng Expanded Metal Machine(From Manufactory) | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
New Design Expanded wire mesh welding equipmentEasy to operate and reliable.
Low noise and energy consumption
New Design Expanded Wire Mesh Welding Equipment
The machine are used for punching shear the cold crimped engine bed with the thickness of 1.2-1.5mm2 the width of 2000mm material strength of 450N/mm,the specifications of punching shear are su~eyed by the bit of TB5-20 mesh grid plate.
Type | FT25-6.3A | FT25-16 | FT25-25 | FT25-63A | FT25-63B | FT25-100 |
| Depth(mm) | max.1.0 | max.1.0 | max.1.5 | max.2.5 | max.3 | max.4 |
| Punching Width(mm) | 500 | 1000 | 1250 | 2000 | 2000 | 2000 |
| Times | 180/min | 150/min | 150/min | 70/min | 45/min | 60/min |
| Distance(mm) | 0-1.15 | 0-1.2 | 0-1.2 | 0-4 | 0-4 | 0-4 |
| Length of Mesh(mm) | max.20 | max.25 | max.30 | max.100 | max.200 | max.150 |
| Motor | 2.2KW | 3KW | 4KW | 11KW | 11KW | 15KW |
| Weight | 0.95T | 2T | 3T | 10T | 10T | 12T |
| Measurement (mm) | 950 x 570 x1780 | 1800 x 1320 x1550 | 1940 x 1600 x 2010 | 2400 x 3500 x 2300 | 2400 x 3500 x 2300 | 3600 x 2500 x 3000 |
Contact Us
- Huanghua Feiteng Wire Mesh Machine Co., Ltd.
- Contact nameJudy Zhao Chat Now
- Phone86-317-8886955
- AddressMold City, Development Zone
