Home > Products > Pipe Flange > ASTM A105 carbon steel flange, class 150 flange, weld neck flange
ASTM A105 carbon steel flange, class 150 flange, weld neck flange
- 10000 Piece / Pieces per Month
- Tianjin Port
- T/T
You May Like
Product Details
| Size | 20" | Material | Other, Carbon Steel, ASTM A105 | |
| Standard | Other, ASME, ASME B16.5 | Place of Origin | Hebei, China | |
| Model Number | ZY-WNF | Brand Name | ZHONGYAN | |
| Standard or Nonstandard | Standard |
Product Description
Specifications:
ASTM A105 carbon steel flange, class 150 flange, weld neck flange
Type: Weld neck Flange
Face: RF
Size: 20"
Pressure: 150 Lbs
Standard: ASME B16.5
Material: ASTM A105
Detailed information:
| Type | Flange |
| Size | 1/2"-48" |
| Face | RF, FF, MFM, RJ, TG |
| Pressure | Class 150Lbs, 300Lbs, 600Lbs, 900Lbs, 1500Lbs, 2500Lbs |
| Standard | ANSI B16.5, HG20595-1997, HG20617-1997, GB/T9115.1-2000, GB/T9115.4-2000, DIN2630-2638 |
| Material | ASTM A182,F304, F304L, F316, F316L, F51,F53,F321,F904L |
| Process | forging, casing, plate cutting |
Surface Treat | Anti-rust Oil, Paint, Zinc, Hot dipped Galvanized |
| Application | - Piling project - Heat-supply project - Conveying drinking water,drainage,coal gas,fuel gas,mine slurry and other low & middle pressure fluids - API5L Petroleum and natural gas pipeline - Chemistry industry - Electric power engineering circulating pipe |
Production Flow
More Products
Threaded flange Square flange
Blind flange Slip on flange
Application
ASTM A105 carbon steel flange will be packed with wooden case or pallet or as per customers' requirements.
