Automatic Plastic Film Slitting Rewinder Machine 300M/Min
- Ningbo Shanghai
- T/T
You May Like
-
Automatic Slitting And Rewinding Machine For BOPP/PET/PVC Shrink Film/Laminated Film
-
Polyester Film Slitting Rewinding Machine
-
Center Roller Surface Winding Slitting Machine (Model FQ-E)
-
Bottle Label Slitting Rewinding Machine
-
FQ-ES Plastic Film Slitting Rewinder
-
10mm Width Non Woven Slitting Machine
Product Details
| Condition | New | Type | Slitting Rewinder | |
| Computerized | No | Place of Origin | Zhejiang, China | |
| Brand Name | Hongyu | Model Number | FQ-E Series | |
| Voltage | 380V 50HZ 3Phase | Power(W) | 4kw | |
| Dimension(L*W*H) | 2600*1700*1100mm | Weight | 2100kg | |
| Certification | CE Certificate | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
USAGE
FQ-E Series slitting machine suit for slitting&rewinding thin film such as PZG、PET、EVA、PE、LDPE、LLDPE、HDPE、BOPP、OPP、CPP、PVC、BOPS、PVDC、Optical Thin Film Etc...
FQ-E Slitter with good machine structure,low noise,easy to operating & maintain. It equipped with quality performance tension controller,Rewinding meter counter and low noise. Film slit by this machine have very smooth edge.Feature
1.Machine adopt friction center rewinding technology.
2.Euiqped with waste edge cutting and sending device ,make your final product smooth and perfect surface.
3.Double air expanding shaft to rewinding ,Rewinding surface smoothly.
4.Automatic meter counter , can count the meter when it working.
5.Automatic EPC for unwinding, photocell is suitable for tracking the edge and color of transparent material.
6.Machine & All the electric appliances has been gained the CE certificate.
1.Filtration Pressure Regulating Valve 2.The 1st Rewinder Pressure Regulating Valve
3.The 2nd Rewinder Pressure Regulating Valve 4.Air Expanding Shaft Gas Charging Valve
5.The 1st Rewinder Unload Button 6.The 2nd Rewinder Unload Button 7.Unwinder Right Air Cylinder 8.Unwinder Left Air Cylinder
9.Button Of (7&8 Right Left)Cylinder 10.Material Lengthways Adjust Wheel
11.Material Crosswise Adjust Wheel 12.Magnetic Powder Brake
13.Slitting Blade Worm Wheel 14.Rewinding Shaft Wheel 15.Air Expanding Rewinding Shaft
Certificate From Italy
1.This machine is center friction rewinding type .Machine frame made of 4CM thickness steel plate and with good machine structure. Make sure machine won’t shake in high speed running.
2.Unwinding tension controller adopt 10Kgs magnetic brake ,can make tension between 10-200N.
3.Unwinder with photocell eye and deviation correct motor to correct unwinding deviation. Make sure film send smooth & flat.
4.Flat Blade To Slitting. And With Blade Shim Roller.
5.Center Friction Rewinder. Make Rewinding effect and material edge smooth. Rewinder also equipped with waste edge sending device.
Warranty
* 1 year warranty
* Any part of electronic ,if it's not cause by man-made reasons,we will ship you a free new one.
* If beyond warranty,we offer free repair service,Clients need undertake ship cost.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
*In Malaysia.Philippines.Indonesia. We have local engineer ,but client please undertake travelling expenses for them.
