Flat Pack Modern City Bar Steel Container House Price for UK

1

40ft contatiner Store/shop,area:29 square meter

2

The house including:

3

Building cost estimated:5,000USD-8,000USD (Not include furnitures)

4

Specification for Each 20ft contatiner home as following:

 Dimension

1.

20ft container home Dimension

exterior size: 5800mm x 2500mm x 2670mm

area: 14.5 square meter

2

Packing Size

5800mm*540mm*2500mm

3

Weight

About 1300kg

4

Contatiner capacity:

40HQ: 8 units

5

Life span

20 years

6

Usage

Office,house,living room,rest room,activity room, bar,Villa, etc

Roof System

7.

Roof frame

Roof Steel Frame

Dead load

230kg/m2

Live load

180kg/m2

Roof Surface

Galvanized Steel Plate

Roof Insulation

EPS sandwich board
Insulation Sponge

Waterproof

Glass Glue and some folding parts

Strength

Glass Magnesium Board

Lifting parts

Lifting Bolt

Ceiling

Ceiling Board

Ceiling Edging Board

Base system

8

                         Floor

15mm Wood Plastic Board
8mm Laminated Wood Board
2mm Resists Corrosion Paper

Dead load

280kg/m2

Live load

230kg/m2

Base frame

Base Steel Frame

Pipeline system

optional

Wall system

9

Door:

50mm EPS sandwich door with lock
key and stopper
High quality steel door(optional)

Outside Decorative

WPC Decorative Board (Optional)

Wall System

50mm EPS sandwich panel with sealing stripe

Window

Double glass alloy window with security frame

Interior partition board

50mm EPS sandwich panel

1

Safty and reliable light steel flexible structural system

2

Easy to transport (can load 8 units in a standard 40ft shipping container )

3

Waterproof, sound-insulated, heat preservation. ( core material can be EPS, PU, Rock wool)

4

Waterproof, sound-insulated, heat preservation. ( core material can be EPS, PU, Rock wool)

5

Widely modal application, the office, conference room, dormitory, store, factory etc

6

Easy to assemble and dismantle:Only few easy step folding to install and unfolding to uninstall

7

Resisting:Standard manufacturing, no construction garbage, Low-carbon green

8

Safe & steady:Earthquake resistance is Grade 8, Wind resistance is Grade 11.
