Hot Sale ShakingTable Concentrator With ISO9001:2008 by Zhongde

FOB Price

US$ 1,500 - 2,000 / Set

1 Set(Min. Order)

Port Tianjin Qingdao Shanghai etc
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Table Concentrator
Place of Origin	Henan, China	Brand Name	Zhongde
Model Number	6-S

Product Description

Specifications

1.Wide application:gold,silver,lead zinc etc.
2.High concentration ratio and efficiency
3.Energy saving
4.Easily operated

Table Concentrator

Introduction:

6-S Type Concentrator Table is a new physical concentrating equipment. It mainly used for concentrating rare metal and rich metal ore such as gold, silver, lead zinc, tantalum niobium, tantalum nickel, tin and etc.

6-S Type Concentrator Table combines the national Concentrator Table and weight concentrating technology. The advantages are high concentration ratio, high concentration efficiency, easily operated, and once get the final concentrate and gangue. it is comparing from the traditional in non-medicine, energy saving, easily deal etc, high performance-price ratio.

Working principle:

The ore processing with concentrator table is on the lean table board. The ore is fed in by the ore feeding chute upper table board; meanwhile, the water is fed by water feeder transversely.

Under the impact of vibrating wave, the materials go on vertical and horizontal movement as the different proportion and granularity.

The ores with different proportion and granularity move down in ladder-shipped state along with their own movement, then are discharged from the different position of fine concentrate end and tailings end. Finally they are divided into fine concentrate, middle concentrate and tailings.

Technical Parameters:

Name		Unit	Grit concentrating table	Fine sand concentrating table	Slug concentrating table
Dimensions	Length	mm	4450	4450	4450
	Driving part width	mm	1855	1855	1855
	Concentrate part width	mm	1546	1546	1546
Max. feeding size		mm	2	0.5	0.15
Feeding amount		t/d	30-60	10-20	15-25
Feeding thickness		%	25-30	20-25	15-25
Journey		mm	16-22	11-16	8-16
Frequency		F	15-48	48-53	50-57
Water quantity		t/d	80-150	30-60	10-17
Horizontal obliquity		Degree	2.5-4.5	1.5-3.5	1-2
Portrait obliquity		%	1.4	0.92	----
Table board corner		Degree	32-42	40	42
Concentrating square		----	7.6	7.6	7.6
Table board length ratio		----	2.6	2.6	2.6
Motor power		KW	1.1	1.1	1.1
