China Professional Manufacture Gold Mining Equipment Gold spiral classifier for sale
USD $3,900 - $19,000
/ Set
1 Set(Min.Order)
- tianjin qingdao shanghai port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Low Price and High Efficiency Spiral Classifier
-
Functional High Efficiency Spiral Classifier
-
Spiral Classifier spiral sand classifier mining classifier
-
Famous Good Quality Spiral Classifier
-
mining classifier for hot sale, hot in Southeast Asia
-
China best professinal manufacturer provide Spiral classifier for hot sale
Product Details
| Condition | New | Type | Other, spiral classifier | |
| Application | mining, building, coal and so on | Motor Type | AC Motor | |
| Power(W) | 30000 | Capacity(t/h) | 8000(sand-return) | |
| Place of Origin | Henan, China | Brand Name | Zhongde | |
| Model Number | FG-10 | Dimension(L*W*H) | 7590*1240*2380 | |
| Weight | depend on the specific product | Certification | ISO,BV,CE certificate etc. | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product Description
Introduction
Spiral classifier,working with ore mills to form close circulation in the concentrating plant,whose classification process depends on the sedimentation velocity of the particles. Its external appearance is a rectangular oblique chute, whose bottom is semi-circular.
Technical parameters
| Model | Spiral diameter(mm) | Trough length(mm) | Spiral rotation speed(r/min) | Capacity:sand-return(t/d) | Capacity: overflow(t/d) | Motor power for driving(kw≤) | Motor power for lifting(kw≤) | Dimensions( Length*Width*Height)(mm≤) |
| FG-5 | 500 | 4500 | 8-12.5 | 135-210 | 32 | 1.1 | - | 5430*680*1480 |
| FG-7 | 750 | 5500 | 6-10 | 340-570 | 65 | 3 | - | 6720*980*1820 |
| FG-10 | 1000 | 6500 | 5-8 | 675-1080 | 110 | 5.5 | - | 7590*1240*2380 |
| FC-10 | 1000 | 8400 | 5-8 | 675-1080 | 85 | 7.5 | - | 9600*1240*2680 |
| FG-15 | 1500 | 8300 | 4-6 | 1830-2740 | 235 | 7.5 | 2.2 | 10410*1880*4080 |
| FC-15 | 1500 | 10500 | 4-6 | 1830-2470 | 185 | 7.5 | 2.2 | 12670*1820*4890 |
| 2FG-15 | 1500 | 8300 | 4-6 | 2280-5480 | 470 | 15 | 4.4 | 10410*3390*4080 |
| 2FC-15 | 1500 | 10500 | 4-6 | 2280-5480 | 370 | 15 | 4.4 | 12670*3370*4890 |
| 2FC-20 | 2000 | 12900 | 3.6-5.5 | 7780-11880 | 640 | 22-30 | 6 | 15760*4600*5640 |
| FG-24 | 2400 | 9130 | 3.67 | 6800 | 580 | 15 | 3 | 11650*2910*4970 |
| FC-24 | 2400 | 14130 | 3.67 | 6800 | 490 | 18.5 | 4 | 16580*2930*7190 |
| 2FG-24 | 2400 | 9130 | 3.67 | 13600 | 1160 | 30 | 6 | 12170*5430*5690 |
| 2FC-24 | 2400 | 14130 | 3.67 | 13700 | 910 | 37 | 8 | 17710*5430*8000 |
| 2FG-30 | 3000 | 12500 | 3.2 | 23300 | 1785 | 40 | 8 | 16020*6640*6350 |
| 2FC-30 | 3000 | 14300 | 3.2 | 23300 | 1410 | - | - | 17091*-*8680 |
Pictures of Products
Packaging & Shipping
Our Services
1. Installation and adjustment of the machine:
Technicist will be provided by supplier for buyer to assist the work such as welding connection
of shell body, equipment installation, adjustment, training, etc.
2. Warrantly period is one year except the easy-wearing parts.
3.Technical support of Spiral Classifier is provided from the beginning to the end.
4.Spare parts of Spiral Classifier are serviced for sale in the whole year.
Company Information
Welcome to visit our company and workshop, we sincerely look forward to cooperating with
you. We will provide you with the most suitable products with the reasonable price.
