Pulling Heavy Duty Underground Coal Mining Lift Winch
- any Port
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Wells | |
| Model Number | JSDB-30 | Type | Other, mining winch | |
| Machine Type | Other, mining winch | Certification | Other, MA | |
| Material | Iron | Processing Type | Casting | |
| Use | Coal Mining |
Product Description
pulling heavy duty underground coal mining lift winch
1.JSDB series adjustable prop-pulling and lifting usage underground mining windlass mainly use for transferring and do other auxiliary transportation work.,
2.JSDB series also could use for dispatching material transportation of mining cars in underground mining working face, mining shaft bottom and so on.
3.It also could use for prop pulling caving on the working face.
4.JSDB winch has fast speed and low speed,it's not only used for low speed winch,but also used for prop pulling winch,it can pulling capacity according to the request in the different condition.
model | JSDB-10 | JSDB-12 | JSDB-13 | JSDB-15 | JSDB-16 | JSDB-19 | JSDB-25 | JSDB-30 | |
slow speed | outer max static tension KN | 100 | 120 | 130 | 150 | 160 | 190 | 250 | 300 |
inner max static tension KN | 140 | 160 | 200 | 250 | 280 | 320 | 390 | 470 | |
| average static tension KN | 120 | 140 | 165 | 200 | 220 | 250 | 320 | 380 | |
average rope speed m/s | 0.136 | 0.14 | 0.133 | 0.14 | 0.16 | 0.15 | 0.16 | 0.16 | |
high speed | outer max static tension KN | 12 | 14 | 15 | 18 | 20 | 25 | 30 | 38 |
outer max rope speed m/s | 1.03 | 1.17 | 1.24 | 1.37 | 1.53 | 1.5 | 1.53 | 1.5 | |
drum | diameter mm | 380 | 400 | 435 | 470 | 510 | 545 | 540 | 650 |
width mm | 408 | 408 | 530 | 530 | 560 | 770 | 760 | 885 | |
rope capacity m | 120 | 150 | 180 | 200 | 300 | 400 | 500 | 700 | |
wire rope | rope diameter mm | 20 | 22 | 24 | 26 | 28 | 30 | 30 | 36 |
frame |
6*19 | ||||||||
strength Mpa | 1670 | ||||||||
motor | power Kw | 18.5 | 22 | 22 | 30 | 37 | 45 | 55 | 75 |
speed r/min | 970 | 980 | 740 | 980 | 980 | 990 | 990 | 990 | |
size
| length mm | 2630 | 2630 | 3158 | 3220 | 3420 | 3520 | 4000 | 4330 |
width mm | 990 | 927 | 1110 | 1000 | 1020 | 1254 | 1270 | 1403 | |
height mm | 855 | 855 | 1030 | 1050 | 1070 | 1150 | 1255 | 1528 | |
| weight | weight Kg | 2000 | 2400 | 3780 | 3920 | 4030 | 5000 | 8300 | 8900 |
product | pulling heavy duty underground coal mining lift winch | ||||||||
Xuzhou Mine Equipment Manufacturing Co., Ltd. comes from XCMG Mining Equipment Factory, founded in 1956, which belongs to National Machinery Department. Since 2001, it reformed as a private owned enterprise, our factory located at the foot of JIULI mountain, where has been always treated not only as a crucial transportation junction, but also a business center.
As a leading manufacturer of mining equipment in China, we have been devoted to creating new and quality products in mining field for more than 50 years. The factory site covers around 100,000 square meters, with registered capital of US$ 5 million and more than US$ 36 million permanent assets,having more than 300 workers, including 50 engineering technicians,owning 180 sets of machining equipment totally, including various kinds of high-end, huge, rare inspection devices, and with complete supplying and service system. Our sales network has been expanded to all the mining group in every province, city and autonomous region. Also exported to Vietnam, Russia, Bengal, India, Malaysia, Mongolia etc. The sales turn over has successfully reached US$ 30 million.
We insist on the principles of work are:
To set up a brand name’s image with high quality products
To enlarge the market with good credit
To gain sustainable development with continuous creativity
To retain client’s faith with satisfying service
Our skilled workforce combined traditional skills with modern approach through the use of conventional and latest machinery. Dispatching winch has been awarded national silver medal and under strict management and excellent performance in the industry, we have been praised as a high quality product enterprise four times, high & new technology enterprise in Jiangsu province once, and passed ISO9001:2008&GB/T9001-2008 quality accreditation, reputed as the provincial measurement confirmation unit.
Q1:Are you manufacturer or trader?
A: We are factory.
Q2.Do you have any certifications?
A. We have all safty CE,such as ISO ,MA,EI and so on.
adjustable proo-pul pulling heavy duty underground coal mining lift winch ling and lifting usage underground mining winch prop-pulling and lifting usage underground mining windlass
