Automatic high speed stack door

Specifications

The specification of automatic high speed stack door

1) The door body structure

uses the cold rolling steel plate from Shanghai Baoshan Steel Coporation production, the surface after many times superficial rust prevention processing, after 250°C high tepid stove powder spray coating processing, the surface
sharp, guards against delimits wear-resisting, the color may elect. Plate thickness is 2.0mm.(In track after special design, reduced and curtain cloth rubs in wind pressure big situation)

2) The drive

uses the Taiwan SLM branch electrical machinery, power source 220V, power 1.5kw, the load bearing shoulders S4 greatly

3) The electrically controlled system

uses the Danish Danfoss,high performance promotion control box, in sets at the vector control pattern, the control precision is high; The high torque frequency changer (150%1HZ), PLC combines, has the high performance, the redundant reliability, the high stability, high characteristics ,high accurately localization. Simultaneously utilizes the frequency conversion control technology, has the soft start, slow stop function, guarantee door body revolution steady increase service life.

4) Operation speed

0.4-0.8m/s opening speed (adjustable). High frequency opening (800-1500/day)

5) Safety device

Under the doorframe installs infrared photoelectricityprotection switch one pair, under the gate body pauses when the human and the object block the photoelectricity, gate body will not whereabouts.(South Korean Otto Nix)

6) The curtain

selects the French import industry to gather fat textile fiber cloth, the high strength environmental protection gathers the fat textile fiber, the two-sided polyvinyl-chloride coating, thickness is 0.9mm, the color: Yellow. Anti-tearability: 600/600 (after/latitude), longitudinal strength: 4000/3500 (after/latitude), peeling intensity Newton /5 centimeter, application temperature - 30--+70°C, the fire protection standard (German DIN75200) cloth has the nontoxicity, good clean surface; The botton of the curtain installs the gas cloth, the leak-proof quality is good, does not accumulate the dust, easy clean.

7) The wind resistant effect

curtain cloth engagement spot is loaded with the wind steel tube, the increase wind resistant effect.

8) The welding

uses the newest large-scale high frequency welding apparatus, the completely automatic splices a formation, the joint is neat, does not have the wrinkle, does not have the tool marks smoothly, the splicing perfect surface, never opens the rubber. Solves specification which the small welding machining is unable to achieve.

9) Transparent Windows

Install the PVC transparent Windows horizontally in the middle of the door,when the personnel and the vehicles through increased the security and the management conveniences.

10) The seal

curtain base is loaded with the aerocyst cloth pouch, may with each kind of not smooth ground strict union, in the guide rail set at the hair brush, may play dustproof, insectproof and seal .

11) The control mode

uses the two-sided manual push-button control and auto-induction control

12) The limit switch

uses the Winsion Brand range finder, the localization is accurate.

13)Outage emergency configuration

machine to have opens the door urgently the installment namely manual rocking bar, when meets by chance the power cut or has the contingency may guard a door with ease swings.

14) Fault recovery function

Each machine of Winsion Company production have the falt recovery function, after closes the power source 10 seconds , the system will self-recovery.
