Home > Products > DTH Hammer Drilling Rig > DFQ-200C Truck Mounted Air Compressor Water Well Drill Machine, Hydraulic Water Well Drill Rig Air Compressor 200m Depth
DFQ-200C Truck Mounted Air Compressor Water Well Drill Machine, Hydraulic Water Well Drill Rig Air Compressor 200m Depth
- Qingdao/ Tianjin/ Shanghai
- T/T Credit Card
You May Like
-
High Quality 200m Deep Hard Rock Drilling Rigs DFQ-200
-
DFQ-200 Crawler DTH Water Well and Rock Blasting Drilling Rigs for Sale
-
Widely Used Hydraulic Water Well Drill Rig Machine DFQ-200
-
200m Truck Mounted Water Well Drilling Rig DFQ-200C With DTH Hammer and Bits
-
DFQ-200 Hydraulic Crawler Drilling Machine Rig for 200m Water Well
-
The Best Saler DTH Drill Rig, DFQ-200 Hydraulic Crawler DTH Drilling Rig
Product Details
| Condition | New | Type | Other, top drive | |
| Power Type | Other, diesel engine | Place of Origin | Henan, China | |
| Brand Name | DEFY | Model Number | DFQ-200C | |
| Usage | Water Well | Voltage | Customized | |
| Power(W) | 50KW | Dimension(L*W*H) | 6000*1900*2800mm | |
| Weight | 6500kgs, 6500kgs | Certification | BV&SGS | |
| Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
DFQ-200C Truck Tounted Water Well Drill Machine Work wiht air compressor and Mud Pump
Brief Introduce
1. water well drilling,
2. geothermal air-conditioning project and other boreholes,
3. especially applicable to mountain area and rock formation water engineering.
Features
Drilling diameter | 100 - 400 mm |
Max. Depth | 200m |
Max. hoist lifting force | 10T |
Rotation speed | Slow 20r / min |
Quick 100r/min | |
working air pressure | 1-3.45MP |
Drill rod | 89x8x3300mm |
Drill tower height | 4-7 m |
Power | 50kw diesel engine |
Besides DFQ-200C 200m truck mounted water well drilling rig for sale, we also have 100m, 150m, 250m, 300m, 400m drilling rigs for your choice.
Model | Movement | Borehole Diameter | Drilling Depth |
DFQ-100 | Crawler | 105~150mm | 100m |
DFQ-100W | Wheel trailer | 105~150mm | 100m |
DFQ-150 | Crawler | 105~203mm | 150m |
DFQ-150W | Wheel trailer | 105~203mm | 150m |
DFQ-200 | Crawler | 105~203mm | 200m |
DFQ-200W | Wheel trailer | 105~203mm | 200m |
DFQ-250 | Crawler | 105~254mm | 250m |
DFQ-300 | Crawler | 105~305mm | 300m |
DFQ-400 | Crawler | 105~400mm | 400m |
DEFY SERVICE
1. Provide factory cost accessories all year
2. Engineers are available to service machine overseas or free training in factory
3. Online service 24hours*7 days
4. 12 months quality warranty for main body.
DEFY Certificate
How to choose a suitable drilling rig?
1. What will you do using drilling rig?
---For water project, core sample, soil test, mineral prospect or others?
2. The depth you need?
---For water well, generally, 30-200m. For core sample, 30-600m, even more.
3. Any requirements to hole diameter?
---Within a certain range, the smaller diameter, the deeper depth. Mathematically, we call it inversely proportional.
4. Working land condition?
A. soil, sand, weathered land, etc. soft stratum.
B. soil, sand, soft and hard rock stratum, mixed one.
C. Mainly hard rock, like granite.
Based on the above information, DEFY experienced engineers will help you recommend suitable machine and price. If you have special demands, please tell us ahead.
Please feel free to contact Andrew for More Details and Best Offer!!
Skype: live:defy-drillingrig
Mobile/WhatsApp: 0086-18681448031
Office line: 0086-371-55819257
Email: andrew(at)
Website:
Facebook: /cndrillingrigs
Contact Us
- Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.
- Contact nameLisa Si Chat Now
- Phone86-371-55819257
- Address No.96 Ruida Road, High-Tech Zone, Zhengzhou City, Henan Province, China, Zhengzhou, Henan
