Home > Products > Drilling Accessories > BW-160 Drilling Mud Shear Pump
BW-160 Drilling Mud Shear Pump
- Qingdao Shanghai or as required
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | DEFY | |
| Model Number | BW-160 | Structure | Single-stage Pump | |
| Standard or Nonstandard | Standard | Fuel | Diesel | |
| Pressure | High Pressure | Power | Other, 5.5kw, 8 HP | |
| Application | Other, use together with drill rig |
Product Description
Specifications
Drilling Mud Shear Pump-160 L/min theoretical flow
-L1110xW725xH965mm
-Easy operation, long service time
BW-160 Independent mud pump is a new type pump which is widely used in engineering geological drilling industry, small water well drilling hole flushing fluid and so on.
Technical Parameters for BW-160 mud pump
No. | Name | Technical Parameters |
1 | Model | BW-160 |
2 | Number of cylinders | 1 |
3 | Cylinder diameter | 95mm |
4 | Piston stroke | 85mm |
5 | Frequency | 165 time/min |
6 | Theoretical flow | 160 L/min |
7 | Rated pressure | 1.3Mpa |
8 | Volume efficiency | 88% |
9 | Belt wheel speed | 951rpm |
10 | Power | 5.5kw/8HP |
11 | Inlet inside diameter | 42mm |
12 | Outlet inside diameter | 32mm |
13 | Weight(including power) | 200kg |
14 | Dimension | L1110xW725xH965mm |
Service from Defy
* One year quality guarantee
*Spare Parts are available at factory price
* Quick response by professional engineers and sales team
* Face-to-face training in clients' worksite or FREE training in our factory.
BV & SGS & BUSINESS LICENSE & CUSTOM CERTIFICATE for DEFY
