Premade Juice Pouch Filling Sealing Machine
Negotiable
/ Set
1 Set(Min. Order)
- shantou
- T/T Money Gram Credit Card
You May Like
-
Bean Curd Plastic Bag Filling Sealing Machine
-
Flavoured Drink Filling Machine
-
SD-8 Plastic Bag Filling Sealing Machine
-
8 Head 8 Nozzles Plastic Bag Filling Packing Packing Machinefor Juice, Water, Jelly
-
8 Head 8 Nozzles Plastic Water Bag Filling Sealing Packing Packing Machine
-
Hot Sale Flavored Drink Plastic Expansion Preformed Bag/sachet/pouch Filling Sealing Packing Packing Machine
Product Details
| Condition | New | Application | Food, Beverage | |
| Packaging Type | Stand-up Pouch, Bags, Pouch, Other, Stand-up Pouch, Bags, Pouch, Wooden case | Packaging Material | Plastic, Other | |
| Automatic Grade | Semi-Automatic | Driven Type | Other, electric and penumatic | |
| Power | 1.5KW | Place of Origin | Guangdong, China | |
| Brand Name | SY | Model Number | SD-8 |
Product Description
laminated film bag filling packaging machine1.
The machine is suitable for filling and sealing different drinks,such as jelly,milk,oil,juice and so on.
2.The machne is suitable for different shape and volume bags.we can design different needle according to the cusomers'demands.
3.The machine has 8 dosing heads.each 4 is a group,can be fillled different volums each group at the same time.
| Name | Quantity | |||
| Ari cylinder | 8 | |||
| Magnetic valve | 10 | |||
| Filling pump | 8 | |||
| Relay | 12 | |||
| Plc switch | 7 | |||
| Panel switch | 6 | |||
| Filling switch | 2 | |||
| power supply | 1 | |||
| Incko (temperature controller) | 2 | |||
| Power using | 220V | |||
| Electric consumption | 1.5kw | |||
| Air pressure using | 0.5mpa-0.7mpa | |||
| Max air consumption | 0.3m3/min(external air sourse) | |||
| Dimension(L*W*Hmm) | 1700*1470*1850 | |||
| Infeeding tank size(L*W*H mm) | 470*250*420 | |||
| Weight (kg) | Approx 400kg | |||
| Productivity | 2000-2500bags/h | |||
