UL3289 crosslinked PE insulation 18 guage electronic wire
- Port of Shanghai
- T/T
You May Like
-
UL3386 24 awg stranded bare copper electrical wire
-
UL3386 24 awg stranded tinned copper electrical wire
-
UL3386 30 awg stranded bare copper electrical cable wire
-
UL3386 30 awg stranded tinned copper heat resistant insulation for electrical wire
-
UL3386 xlpe insulated 28 awg annealed copper wire
-
UL3386 AWM 28 XLPE insulated electrical copper wire
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Winpower | |
| Model Number | UL 3289 18 AWG 16/0.254mm | Type | Insulated | |
| Application | Other, electronic wire | Conductor Material | Copper | |
| Conductor Type | Stranded | Insulation Material | PE |
Product Description
UL3289 crosslinked PE insulation 18 guage electronic wire
All our wires and cables are made of 99.99% pure oxygen free copper and high quality PE which comply with the European Union RoHS environmental protection instruction.
SPECIFICATION: 18AWG
REFERENCE STANDARD: UL758,UL1581,CSA C22.2No.210.2
F LAME TEST: CSA FT2 flame test
RATED TEMPERATURE: 150 Deg Centigrade
RATED VOLTAGE: 600v
CONDUCTOR: 16/0.254mm stranded tinned copper
INSULATION THICKNESS: 0.77mm
PE OUTER DIAMETER:2.80 mm
MAX. CONDUCTOR RESISTANCE: 23.2 Ω/km
DIELECTRIC STRENGTH: 2000v
CONDUCTOR | INSULATION | MAX.COND. RESISTANCE (Ω/km,20°C,DC) | DIELECTRIC STRENGTH (VAC,1min) | |||
AWG | CONSTRUCTION (No./mm) | DIA. (mm) | THICKNESS (mm) | O.D. (mm) | ||
30 | 7/0.10 | 0.30 | 0.77 | 1.90 | 381 | 2,000 |
28 | 7/0.127 | 0.38 | 0.77 | 2.00 | 239 | 2,000 |
26 | 7/0.16 | 0.48 | 0.77 | 2.10 | 150 | 2,000 |
24 | 11/0.16 | 0.61 | 0.77 | 2.20 | 94.2 | 2,000 |
22 | 17/0.16 | 0.76 | 0.77 | 2.35 | 59.4 | 2,000 |
20 | 26/0.16 | 0.94 | 0.77 | 2.55 | 36.7 | 2,000 |
18 | 41/0.16 | 1.18 | 0.77 | 2.80 | 23.2 | 2,000 |
16 | 26/0.254 | 1.50 | 0.77 | 3.15 | 14.6 | 2,000 |
14 | 41/0.254 | 1.88 | 0.77 | 3.55 | 8.96 | 2,000 |
12 | 65/0.254 | 2.36 | 0.77 | 4.05 | 5.64 | 2,000 |
10 | 105/0.254 | 3.10 | 0.77 | 4.90 | 3.546 | 2,000 |
