Home > Products > Battery > TOP/OEM 2016 NEW Tub Lithium Battery Electric Bike

TOP/OEM 2016 NEW Tub Lithium Battery Electric Bike

FOB Price

US$ 160.00 - 180.00 / Set

20 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Part	Other, battery for ebike		Place of Origin	Zhejiang, China
Brand Name	TOP/OEM		Model Number	TP36V

TOP/OEM 2016 NEW Tub lithium battery electric bike

Item	Specification
Voltage and Capacity	36V10AH
Nominal Capacity	10Ah (24V discharge@23°C )
Minimum Capacity	9.8Ah (24V discharge@23°C )
Nominal Voltage	36 V
Charging Voltage	43.8V ±0.1V
Charging Method	CC-CV(constant voltage with limited current)
Standard charge	0.5C constant current(CC) charge to 43.8V,then constant voltage (CC)43.8V charge till charge current decline to ≤0.05C
Standard charge
Max. Discharge Current	30A(ambient temperature 25°C)
Discharge Cut-off Voltage	30V
Operation Temperature Range	Charge: 0~45°C(60±25%R.H)
Operation Temperature Range	Discharge: -10~50°C(60±25%R.H)
Storage Temperature	1year:-20~25°C(1*)
	3months:-20~45°C(1*)
	1month:-20~50°C(1*)
Pack Weight	About 5Kg

Why Li-ion Battery?

Longer battery life - at least 3 times longer than lead acid batteries
Easy carrying and installation - can be carried and installed in any direction
Fast charging - about 4~6 hours to be fully charged
Lighter weight - 1/2~1/4 in weight compared to lead acid batteries
Require no change to a lead acid battery charging system
Better safety - mild warm, no explosion and firing, free of leakage
Low self-discharge
Free of charge memory
Steady discharge and charge performance.
Outstanding thermal stability
Wide temperature performance
Short circuit protection
Over charge and over discharge protection
Over current protection
Environmentally friendly - no poisonous lead, no acid, no heavy/rare metals, no gasses during charge, free of leakage and pollution
No recycle required
