Product Details
| Condition | New | Application | Medical | |
| Packaging Type | Bottles | Packaging Material | Glass | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220V, 220V | Power | 60kw, 60Kw | |
| Place of Origin | Hunan, China | Brand Name | FE | |
| Model Number | BXAZ | Dimension(L*W*H) | 9200*2100*2600 mm | |
| Weight | 7000kg, 7000Kg | Certification | GMP/CE, GMP,CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Complete 1ml Ampoule Vaccine Making Production Line
Main Usage:
1.This production line is made up of CLQ vertical ultrasonic washing machine,RSM drying &sterilizing machine,AGFfilling &sealing machine ,
2.which can complete the following functions of ultrasonic washing,rinsing ,air-charging,siliconizing,drying&sterilizing, cooling,filling,sealing
Main techncial parameter:
Model | Single machine | Suitable size |
Capacity | Power | (Kg) Net weight | (mm) Overall dimension |
BXAZ1/20 | CLQ100 |
1-20ml | 1-2ml :30000pcs/ |
60Kw,30Kw 60Kw,Real consumption:30Kw |
7000 |
9200*2100*2600 |
5ml:21000pcs/h | ||||||
10ml:17000pcs/h | ||||||
RSM620/38 | ||||||
20ml:12000pcs/h | ||||||
AGF10/1-20 | ||||||
BXAZ1/10 | CLQ120 |
1-10ml | 1-2ml:36000pcs/h |
84Kw actual consumption 44Kw |
8000 |
10400*2300*2600 |
RSM900/60 | 5ml:25000pcs/h | |||||
AGF12/1-10 | 10ml:20000pcs/h |
Characteristics:
1.It adopts advanced ultrasonic washing ,alternating flushing with multiple needle separately ,laminar flow hot air drying &sterilizing ,laminar flow purifying,multiple-needle filling , sealing.
2.It is characterized by compact structure,small occupying area, high automation ,fewer operator.
3.It adopts photoelectric technology, servo motor,PLC and color touch LCD screen control system. with high automation ,fewer operator .
4.It is suitable for ampoule with different specifications and wide compatiblity,easy to exchange specification parts.
