Home > Products > Construction Equipment > Hot Selling Thread Rolling Machine
Hot Selling Thread Rolling Machine
- Tianjin
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Application | Rebar | |
| Production Capacity | according to the model | Place of Origin | Hebei, China | |
| Brand Name | Ron-en | Model Number | TJ-3TGT | |
| Voltage | Customized | Power(W) | according to the model | |
| Dimension(L*W*H) | 650*600*750 | Weight | 440kg | |
| Certification | CE Certification | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
welcome to visit Ronen company!
Our screw rolling machine is a necessary machine for making screws and coil nails with thread. The usage is very wide, with our advanced technology, our product is very popular in Russia, Uzbekistan, India, Tailand,Algeria,Nigeria and other coutries.
Advantage:
Rolling-through and fixed mode for option.
Under fixed rolling mode,adopt eccentric-type process for thread extrusion.
Adopt cardan joint for connection and drrove by worm gear and rod to improve the product quality .
Specially for set screws and fastening screws.
Equipped with additional vibration disc to realize full automatic production so that the manpower can be saved effectively.
Technical data:
| item | TJ-3TGT |
| Diameter range for the threads rolled | 2-10mm |
| Range of pitch rolled | 0.4-1.5p |
| max length pf the thread rolled | Noilmit |
| rotation speed of rolling die | 30rpm |
| outside diameter/inside diameter and thickness of rolling die | 100/50.5/30mm |
| min center distance between die spindles | 90mm |
| max center distance between die spindles | 130mm |
| center diatance from the lathe bed to rolling-die | 85mm |
| machine motor | 2HP |
| weight | 440kg |
| overall dimension(LXWXH)m/m | 650*600*750 |
| packing dimension (LXWXH)m/m | 880*760*760 |
picture show:
wooden box, wooden pallet
Within 30days after receive the advance payment
1.Production experience:Absorbed ,Professional
2.Each link strict control the quality
3.Our goals are not do the lowest price to do the best quality
4.Provides you with technical guidance
5. The long-term supply all kinds of spare parts, make sure that you use perennial
6. To offer our customers workshop design
7. Choose a professional supplier will bring you more convenient
