Home > Products > Hongda Mixing machine and blenders > 2D Motion Blender Mixer
2D Motion Blender Mixer
- Shanghai
- T/T
You May Like
Product Details
| Mixer Type | Homogenizer | Application | Powder | |
| Place of Origin | Jiangsu, China | Brand Name | Hongda | |
| Model Number | 2D Series | Certification | ISO9001 |
Product Description
Specifications
1. blender mixer is made of sus3042. 2 directions moving
3. mixing high tonnage material
4. turnover swing movement
Main application:
The blender mixer is suitable for the mixing of dry granule materials for pharmaceutical, chemical industries, etc., especially for the mixing of materials with high tonnage.
Working principle:
1) The mixing tank is a cylinder-shape barrel without any stirring device inside, which makes the self-rotation around its axis and also produces invert swing movement around its plane axis synchronized2) Therefore, the target materials inside the barrel could be mixed diffusely and moveably3) It is featured with short mixing time, good uniformity, big output, convenient to discharge, etc.
Inner packing: plastic packingOuter packing: wooden case
Technical Parameters:
Model | Barrel volume | loading capacity | Max loading weigh | No.of swing& rotation | Total motor power | Overall dimension | Barrel weight | Weight(kg) |
EYH-60 | 60 | 30 | 20 | 50 | 0.4 | 700×730×1100(mm) | 15 | 115 |
EYH-150 | 150 | 75 | 50 | 37 | 1.15 | 800×1050×1450(mm) | 50 | 190 |
EYH-300 | 300 | 150 | 100 | 30 | 1.15 | 900×1350×1550(mm) | 60 | 340 |
EYH-600 | 600 | 300 | 200 | 23.6 | 3 | 1170×1640×2050(mm) | 140 | 1150 |
EYH-800 | 800 | 400 | 280 | 19.8 | 3 | 1320×1950×2150(mm) | 200 | 1600 |
EYH-1000 | 1000 | 500 | 350 | 19.8 | 3 | 1360×2040×2300(mm) | 240 | 1700 |
EYH-1500 | 1500 | 750 | 520 | 16.2 | 4.4 | 1580×2400×2550(mm) | 320 | 2000 |
EYH-2000 | 2000 | 1000 | 700 | 16.2 | 7.4 | 1740×2600×2770(mm) | 430 | 2600 |
EYH-3000 | 3000 | 1500 | 1050 | 13.8 | 11 | 1800×2900×2950(mm) | 620 | 3500 |
EYH-4000 | 4000 | 2000 | 1400 | 12.8 | 13 | 1970×3300×3300(mm) | 700 | 4100 |
EYH-6000 | 6000 | 3000 | 2100 | 11.2 | 18.5 | 2300×2900×3800(mm) | 1100 | 6100 |
EYH-8000 | 8000 | 4000 | 2800 | 10.4 | 22 | 2540×4100×4050(mm) | 1450 | 7900 |
EYH-10000 | 10000 | 5000 | 3500 | 9 | 30 | 2900×4500×4400(mm) | 1650 | 9500 |
