ZY2250UV Flatbed Printer

Printing methods:

Drop-on-demand piezo electric

Ink reservoirs:

Refillable on the fly while printing

Ink characteristics:

UV Curable Inks

Printhead controls:

Print head temperature and voltage are software adjustable

Media feeding system:

Free spin / motor-driven lazy loop for optimal banner tension

Media take-up system:

Automatic motor-driven spool 60m (200') capacity

Media handling options:

Roll to roll / Rigid Sheets

Drying system:

UV Lamp

RIP software:

Photoprint 5zhongye Edition

(Windows 2000, Windows Xp Pro SP2)

Color management:

ICC based color, adjustment curves, density adjustment

File formats:

TIFF,JPEG,Postscript 3,EPS,PDF etc.

Electrical requirements:

50Hz/60Hz,220V(±10%)>20A

Environmental requirements:

Ambient temperature20-30,Relative humidity40-70%

Warranty:

1 year (please consult your local dealer for details)

Technical Specification

Model:

ZY2250UV

Printing heads:

Drop-on-demand grayscale piezo electric

No. of Print heads:

5/10 heads (option)

Color:

5 colors (CMYK+W)

Resolution options:

360x360/360x540/360x720/720x720/720x1440 dpi

Printing Speed:

Standard Quality:
High Quality:
Ultra Quality:

               2 bits (3 drops)
10 heads                               5 heads
Up to 43.0 sqm/hr *          Up to 24.0 sqm/hr*
Up to 27.0 sqm/hr *          Up to 16.0 sqm/hr*
Up to12.0 sqm/hr *            Up to 8.0 sqm/hr*

Maximum media width:

225 cm

Maximum printing width:

220 cm

Maximum roll dimensions:

Φ 25 cm

Maximum media thinkness:

4.80 cm

Media Types:

Rigid boards include corrugated, foam core, gatorboard, sintra (PVC), Ceramic tiles,glass,plexiglass, wood, sheet metal, etc.;

Roll to roll include paper, vinlys, adhesive back vinyls, fabrics, etc.

Outdoor durability:

2 years

Dimensions:

4.20mLx1.57mWx1.37mH

Weight(Met)

800kg
