Zy-Uv1850 UV Flatbed Printer

Specifications

one of the biggest and honest manufacturers in china!

TEN YEARS GOLD BRAND!

HIGH QUALITY,LOW PRICE,GOOD AFTER-SALES

1.Technical Specification
Model: ZY1850UV
Printing heads: Drop-on-demand grayscale piezo electric
No. of Print heads: 7 heads (option)
Color: 7 colors (CMYK LC LM+W)
Resolution options: 360x360/360x540/360x720/720x720/720x1440 dpi
Printing Speed:

Standard Quality:
High Quality:
Ultra Quality:                 2 bits (3 drops)
10 heads                               5 heads
Up to 43.0 sqm/hr *          Up to 24.0 sqm/hr*
Up to 27.0 sqm/hr *          Up to 16.0 sqm/hr*
Up to12.0 sqm/hr *            Up to 8.0 sqm/hr*
Maximum media width: 185 cm
Maximum printing width: 185 cm
Maximum roll dimensions: Φ 25 cm
Maximum media thinkness: 4.80 cm
Media Types: Rigid boards include corrugated, foam core, gatorboard, sintra (PVC), Ceramic tiles,glass,plexiglass, wood, sheet metal, etc.;
Roll to roll include paper, vinlys, adhesive back vinyls, fabrics, etc.
Outdoor durability: 2 years
Dimensions: 3.80mLx1.57mWx1.37mH
Weight(Met) 800kg
2.Gerneral Information
Printing methods: Drop-on-demand piezo electric
Ink reservoirs: Refillable on the fly while printing
Ink characteristics: UV Curable Inks
Printhead controls: Print head temperature and voltage are software adjustable
Media feeding system: Free spin / motor-driven lazy loop for optimal banner tension
Media take-up system: Automatic motor-driven spool 60m (200') capacity
Media handling options: Roll to roll / Rigid Sheets
Drying system: UV Lamp
RIP software: Photoprint 5zhongye Edition
(Windows 2000, Windows Xp Pro SP2)
Color management: ICC based color, adjustment curves, density adjustment
File formats: TIFF,JPEG,Postscript 3,EPS,PDF etc.
Electrical requirements: 50Hz/60Hz,220V(±10%)>20A
Environmental requirements: Ambient temperature20-30,Relative humidity40-70%
Warranty: one year warranty

3.Together with the printer: CD for printing software and driver, instruction, for how to install and use it, and maintenance, also the spare parts box.

4.After sell service: anytime online technology support; video support; send technician to your place for helping you. all for free.
