Home > Products > HL Electric actuator > 100N.M Perfect Perfomance Electric Actuators( Direct Installation HL-10)
100N.M Perfect Perfomance Electric Actuators( Direct Installation HL-10)
- NINGBO OR SHANGHAI
- T/T Credit Card
You May Like
-
Modulating Control DC220V Electric Actuators( Direct Installation HL-5)
-
Aluminium Alloy Electric Valve Actuator
-
Aluminium Die-casting Electric Ball Valves Actuator With CE (HL-200)
-
Rotary Electric Actuated With 4~20mA Input Signal (HL-05)
-
Perfect Perfomance Electric Actuator With CE Cerfitication (HL-200)
-
Standard Type Big Torque Valve Electric Actuator( HL-400)
Product Details
| Standard or Nonstandard | Standard | Structure | Ball | |
| Pressure | Low Pressure | Power | Other, electromotion | |
| Material | Alloy | Temperature of Media | Low Temperature | |
| Media | Water | Place of Origin | Zhejiang, China | |
| Model Number | HL-10 | Brand Name | HELI |
Product Description
Electric actuators
*0~90 °rotary
*Guarantee:1 year
*Excellent sealing
*Long time life
*12VDC,24VDC,24VAC,110VAC,220~240VAC,220~240VDC,380~420VAC,50/60HZ
*ON/OFF control ,passive contact control,position signal control,opens degree signal,Modulating control
*T/T, L/C, Western Union
*high quality,low noise
*body material: aluminium die-casting components
*space heater is optional
Model | HL-10 | ||||||
Voltage | DC12V | DC24V | DC220V | AC24V | AC110V | AC220V | AC380V |
Motor Power | 23W,40W | ||||||
Rated current | 4.8A | 2.4A | 0.32A | 3A | 0.64A | 0.32A | 0.19A |
Output Torque | 100N.m | 50N.m/60N.m/100N.m | |||||
Action Time | 10S | 13S/15S/20S/30S | |||||
Rotary angle | 0~90° | ||||||
Weight | 4kg | ||||||
Voltage-with standing valve | 500VAC/1minute | 1500VAC/1minute | |||||
Insulated resistance | 100 MΩ/300VDC | 100 MΩ/500VDC | |||||
Protection Class | IP67 | ||||||
Surrounding temperature | -25°C~60°C(The other temperatures can be customized) | ||||||
Installation angle | Any angle | ||||||
Case material | Aluminium-casting components | ||||||
Optional function | Overload protection function, Heater | ||||||
