Flanged PVC Butterfly Valve With Actuator
- NINGBO OR SHANGHAI
- T/T Credit Card
You May Like
-
Butterfly Valve With Electric Actuator
-
Wafer Butterfly Valve With Electric Actuator(Direct Installation )
-
EPDM Wafer Electric Butterfly Valve With Actuator
-
HLF02-24DN Rotary Air Damper Valve Actuator-ON/OFF
-
API Electric Areation Butterfly Valve (HL-10)
-
Metal Seal Butterfly Valve With Electric Actuator(HL-50)
Product Details
| Standard or Nonstandard | Standard | Structure | Butterfly | |
| Pressure | Low Pressure | Power | Other, electromotion | |
| Material | Other, PVC | Temperature of Media | Low Temperature | |
| Media | Oil | Place of Origin | Zhejiang, China | |
| Model Number | HL-20 | Brand Name | HELI |
Product Description
Flanged valve
Model | HL-20 | ||||||||||
Voltage | DC24V | DC220V | AC24V | AC110V | AC220V | AC380V | |||||
Motor Power | 40W | ||||||||||
Rated current | 8.0A | 0.35A | 5A | 0.9A | 0.48A | 0.25A | |||||
Output Torque | 200N.m | 80N.m/100N.m/150N.m/200N.m | |||||||||
Action Time | 10S | 9S/15S/20S/30S/60S | |||||||||
Rotary angle | 0~90° | ||||||||||
Weight | 7kg | ||||||||||
Voltage-with standing valve | 500VAC/1minute | 1500VAC/1minute | |||||||||
Insulated resistance | 100 MΩ/300VDC | 100 MΩ/500VDC | |||||||||
Protection Class | IP67 | ||||||||||
Surrounding temperature | -25°C~60°C(The other temperatures can be customized) | ||||||||||
Installation angle | Any angle | ||||||||||
Case material | Aluminium-casting components | ||||||||||
Optional function | Overload protection function, Heater | ||||||||||
