Home > Products > Electric Ball Valve > Electric V Ball Valve
Electric V Ball Valve
- NINGBO OR SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Ball | |
| Pressure | Medium Pressure | Power | Other, manual | |
| Material | Other, WCB,SS04,SS316 | Temperature of Media | Low Temperature | |
| Media | Water | Place of Origin | Zhejiang, China | |
| Model Number | HL-10 | Brand Name | HELI |
Product Description
Motorized flange butterfly valve
Model
| HL-10 | ||||||||
Power | DC12V | DC24V | DC220V | AC24V | AC110V | AC220V | AC380V | ||
Motor power | 40W,23W | ||||||||
Rated current | 4.8A | 2.4A | 0.32A | 3A | 0.64A | 0.24A | 0.19A | ||
Output torque | 100Nm | 50Nm/60Nm/100Nm | |||||||
Action time | 10S | 13S/15S/20S/30S | |||||||
Circuit control | B,S,R,H,A,K,D,T | ||||||||
Rotary angle | 0-90° | ||||||||
Weight | 4.5 | ||||||||
Voltage-with standing value | 500VAC/1min | 1500VAC/1min | |||||||
Insulated resistance | 100MΩ/300VDC | 100MΩ/500VDC | |||||||
Protection class | IP67 | ||||||||
Surrounding Temperature | -25°C~60°C(The other temperature can be customized) | ||||||||
Installation angle | Any angle | ||||||||
Case material | Aluminium die-casting components | ||||||||
Optional function | Overload protection, heater | ||||||||
shipping clause :
1). Delivery time
After receive deposit,we need 10~15 days to make goods for 1000pcs
2).Payment Terms
100% by T/T in advance for order less than USD 20000.00
We do payment in L/C at sight for order more than USD 50000.00
But always is in T/T,30% deposit and 70% balance before shipment.
3).Supply Ability
500 Set/Sets per Week 2,000pcs/month
4). Sample:
We may need 7 days to make the sample with 1 pc ,
also we need the sample fee and the express fee,but there would be return after place order.
5). MOQ: 1 pc
We can produce other material of valves according to the customers requests,also we can choose the best valves for our customers,which is the most suitable for the working environment.
