2015 sheenstar Carbonated Drinks Production Line
- 40 Set / Sets per Month
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | |||
| Brand Name | SHEENSTAR, SHEENSTAR | Model Number | TH | |
| Voltage | 220V/380V | Weight | 1000-3000KG | |
| Dimension(L*W*H) | 2950*2150*2400 | Processing Types | Juice | |
| Certification | CE ISO, CE,ISO | Warranty | 1 Year | |
| After-sales Service Provided | Overseas service center available |
Product Description
New Technology Carbonated Drinks Production Line
Detailed Product Description
2000bph-30000bph
High quality with sus 304
Automatic with PLC control
New Technology Carbonated Drinks Production Line
(1) all parts of the filling machine touch with the material adopt high quality stainless still. Through the polishing treatment the surface become easy to clean. Sealed material is rubber or EPDM material.
(2) Using programmle controller as the central control,using pressure transmitter, electromagnetic chaos pneumatic servo measurement level to maintian the balance of filling pressure in order to ensure the stability of the liquid surface.
(3) Designed new filling valve for plastic bottle, return-air and filling tank liquid are separation to ensure the cleaning of filling materials.
(4) The filling machine adopts advanced magnetic clutch-type screw cover head, torque is adjustable. Screwing cap is safe and reliable.
Model(DCGF) | 12-12-5 | 18-18-6 | 24-24-8 | 32-32-8 | 40-40-10 | 50-50-12 | 60-60-15 | 80-80-20 |
Number of washing,filling,capping heads | 12-12-5 | 18-18-6 | 24-24-8 | 32-32-8 | 40-40-10 | 50-50-12 | 60-60-15 | 80-80-20 |
Suited bottle specification (mm) | Φ=50-100 H=170 330-1500ML | Φ50-Φ110 H=160-340 | ||||||
Production capacity(350ML) | 2000- | 4000- | 8000- | 10000-12500 | 12500 | 16000 | 20000 | 26000 |
Washing pressure | 0.2-0.25 | 0.2-0.25 | ||||||
Filling pressure | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 |
Motor power | 1.5+0.55 | 2.2+0.55 | 3+0.55 | 5.5+0.55 | 7.5 | 11 | 15 | 19 |
Overall dimensions | 2300×1600 | 2600×1920 | 3100×2200 | 3850×3000 | 4850×3800 | 5750×3550 | 6500×5500 | 7680×6640 |
Weight kg | 2800 | 3650 | 4800 | 6800 | 8650 | 10500 | 12800 | |
