Turbine Nitrogen Gas Flow Meter Made in China
- Tianjin Port
- T/T
You May Like
Product Details
| Place of Origin | Tianjin, China | Brand Name | SURE | |
| Model Number | LDG- |
Product Description
Specifications
Turbine nitrogen gas flow meter made in china1.Integrative or split type
2.High quality and stability
3.1 year warranty
Turbine nitrogen gas flow meter made in china
Photo |
|
|
| ||
Model | LWQ-N | LW9Q-A | LWQ-B | LWQ-C | LWQ-D |
Diameter | DN25 to DN300 (1 to 12 inches) | ||||
Output Signal | Pulse | 4-20mA | No | 4-20mA/Pulse | Optional 4-20mA or Pulse |
Power Supply | +24VDC±15% | +24VDC±15% | Lithium Battery | 24VDC±15% | 24VDC±15% and Lithium Battery |
Accuracy | 2.5% or 1.5% | 1.5% or 1.0% | 1.5% or 1.0% | ||
Flow Range | Standard | Standard or Extended | Standard or Extended | ||
Local Display | No | Yes | Yes | ||
Temperature | No | No | Yes | ||
Communication | No | No | RS485 | RS485 | |
Housing Material | Aluminum Alloy or Stainless Steel | ||||
Impeller Material | Aluminum Alloy or ABS Resin | ||||
Explosion Proof | ExdIIBT6 or ExiaIICT4 | ||||
Protection Level | IP65 | IP65 | IP65 | ||
Diameter | DN25 to DN300 | ||||
End Connection | Flange (Standard: ISO; Optional: ANSI, DIN, JIS) | ||||
|
| ||||
Fluid Temperature | -20°C~80°C | ||||
Ambient Temperature | -30°C~60°C | ||||
Trade Terms: FOB, CIF, CNF, DDU, Courier as customer required.
MOQ: 1pc, The sample is available with certain value.
Port: Any Port in China
Delivery time: Small quantity order will be arranged in 3-7 Days.
Large quantity order will be arranged in 1-2weeks.
Delivery way: Sample order shipped by international express, such as DHL, TNT, UPS, FEDEX,etc...
Regular order shipped by air, ship, or others.
Payment Terms: T/T, LC, Western Union.
