AISI 304/904L/316L Stainless Steel Bar /round Bar Steel

FOB Price

US$ 2,000 - 10,000 / Ton

1 Ton(Min. Order)

Port Shanghai or Ningbo port
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Standard	ASTM, AISI, DIN, EN, GB, JIS	Place of Origin	Zhejiang, China
Brand Name	GISSUN	Model Number	2013.10.8.01
Type	Other	Steel Grade	300 Series
Application	For sue in the Petroleum.Chemical fiber.Paper.Shipbuilding...	Certification	ISO
Outer Diameter	5.5-150MM

Product Description

AISI 304/904L/316L stainless steel bar / round bar steel:

Standard: ASTMA276/276M, A484/484M, A564/564M, A582/582M, A638/638M,A705/705Metc

Dimensions:

Hot-rolled,pickled stainless steel round bar diameter range is Φ5.5~Φ150mm.

Cold-drawn Bright stainless steel round bar diameter range isΦ3~Φ50mm

Centerless Grinding Bright stainless steel round bar diameter range isΦ4.0~Φ100mm

Peeled Bright round bar diameter is from Φ40 to Φ450mm.

Length Range and allowable variation: Length including Specified length,Multiple length and Radom length, the length should be 1000mm minimum

Straightness variation:unless otherwise specified, mechanical application hot-working or cold-working stainless steel round bars are supplied in mechnical straightening state. Straightness variation are as following:

Surface Condition :Hot-rolled,pickled,Cold-drawn,Straightening,Polish, Peeling,Polish,or Grinding,some need to do heat treatment properly according to customer’s request

NOMINAL SIZE DIAMETER mm	h5	h6	h7	h8	h9	h10	h11	h12
1 to 3	-0.004	-0.006	-0.010	-0.014	-0.025	-0.040	-0.060	-0.100
Over 3 to 6	-0.005	-0.008	-0.012	-0.018	-0.030	-0.048	-0.075	-0.120
Over 6 to 10	-0.006	-0.009	-0.015	-0.022	-0.036	-0.058	-0.090	-0.150
Over 10 to 18	-0.008	-0.011	-0.018	-0.027	-0.043	-0.070	-0.110	-0.180
Over 18 to 30	-0.009	-0.013	-0.021	-0.033	-0.052	-0.084	-0.130	-0.210
Over 30 to 50	-0.011	-0.016	-0.025	-0.039	-0.062	-0.100	-0.160	-0.250
Over 50 to 80	-0.013	-0.019	-0.030	-0.046	-0.074	-0.120	-0.190	-0.300
Over 80 to 120	-0.015	-0.022	-0.035	-0.054	-0.087	-0.140	-0.220	-0.350
Over 120 to 180	-0.018	-0.025	-0.040	-0.063	-0.100	-0.160	-0.250	-0.400
Over 180 to 250	-0.020	-0.029	-0.046	-0.072	-0.115	-0.185	-0.290	-0.460

ITEM	HR	ST	CD	CG
Size Tolerance	ASTM A276	h10-h11	h9-h10	h7-h9
Straightnes(mm/m)	4.00	1.00	0.30	0.20
Ovality(%)	70-75% Tol	50% Tol	50% Tol	50% Tol
Roughness(um)	--	Ra3.2	Ra1.6	Ra0.8
