Metal Casing 100Mbps 4 FE RJ45 Ports FTTB GEPON Ethernet ONU
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
4 RJ45 ports 10/100M FTTB GEPON ONU Industrial ONU
-
Metal casing single port gigabit 1000M GEPON ONU
-
outdoor EPON ONU with two channels 10/100M EOC master ONU
-
Plastic casing 1 RJ45 ports 100Mbps ONU EPON GEPON indoor ONU
-
Plastic casing 1 GE port gigabit ONU GEPON ONU
-
FTTH three triple play onu 4 FE ports GEPON CATV ONU
Product Details
| Place of Origin | Guangdong, China | Brand Name | HiOSO | |
| Model Number | HA7204 |
Product Description
Metal Casing 100Mbps 4 FE RJ45 Ports FTTB GEPON Ethernet ONU
HA7204 ONU
ONU (Optical Network Unit) is the user equipment of EPON.
It can end the operation from OLT (Optical Line Terminal) by PON and provide all kinds of broadband services cooperated with OLT.
ONU is configured and managed remotely by OLT.
HA7204 ONU is cost effective customer device with four 100Mbps ethernet interfaces,special designed for FTTH (Fiber to the House) and FTTB (Fiber to the Building).
It supplies 1G bandwidth to business users and residential users.
Technical Specification
Operation | Function support |
Wavelength | 1310TX/1490RX |
Optical power | -1to+4dBm |
Receiving sensitivity | -24dBm |
Max transmission distance | 20 km |
MAC Table | 64 |
Space of buffer storage | 1.25MB |
Number of LLID | 18 (configured) |
MTBF | 100,000 hours |
EPON trait | Support IEEE802.3ah Support Dynamic Bandwidth Allocation (DBA) Support ONU auto-searching and automatic allocation (real-time operation) |
Standard and Protocol | Support IEE802.3IEEE 802.3uIEEE802.3ab Support IEEE802.1q WLAN Support IEEE802.1p QOS |
Network management | Cooperating with centre OLT, implement management configuration and software upgrade to ONU |
HA7204 ONU parameters
Parameter | Specification |
Power Module | DC5V/1Aoutside poweror AC220V/DC-48Vbuilt-in power |
Power consumption | 3.5W |
Operating temperature | -1055 |
Storage temperature | -4070 |
Humidity | 5%90% non-condensing |
Dimension | 26mm(H)*109mm(W)*152mm(D) / height*width*depthoutside power 38mm(H)*218mm(W)*176mm(D) / height*width*depthbuilt-in power |
Order information
Type | Rate (Mbps) | Wavelength (nm) | Fiber port (Optional) | Power (optional) |
HA7204 | 10/100/1000 | 1310/1490 | SC/FC/ST | DC 5V |
AC 220V | ||||
DC -48V |
