2012 hot hid xenon

Specifications

2012 Hot HID Xenon

Specification:

Luminous flux: 2500~3500 lumen

Lifetime: 3500hours

Operating temperature :-40 degree~ +105 degree

Color temperature: 3,000K-30000k

Output power in stable state: 35w /55w

Wiring: high temperature-resistant, high voltage-resistant

Cover: crystal glass tube of UV-CAT anti-ultraviolet

Quality warranty: 1-1.5 year warranty

type:headlight

Car Make:All cars

Place of origin:Guangzhou,China(Mainland)

HID Xenon Models:

HID Single Beam : H1, H3, H4-1, H7, 9004-1, 9005, 9006, 9007-1, with 2 ballasts and installation clamps.

HID Hi-lo Beam : H4-2, 9004-2. 9007-2 hid for low beam and halogen bulb for high beam, with 2 ballasts and installation clamps.

HID Telescope : H4-3, 9004-3, 9007-3, single HID can switch between high beam and low beam, with 2 ballasts and installation clamps.

HID Bi-xenon : H4-4, 9004-4, 9007-4, 2 HID bulbs on each bulb, which works for high and low beam, with 4 ballasts and installation clamps.

HID Xenon Color Available:
3000k~golden color
4300k~yellow white
6000k~shallow yellow
8000k~blue white
10000k~Cambridge blue
12000k~ Bluish-purplish
15000k~blue red
20000k~pink
25000k~mauve
30000k~purple

Strict-Testing on HID Xenon:
•High/low Temperature Testing;
•IEC 68-2-6 Tremor Testing;
•EN60529 Waterproof and Dustproof Testing;
•DIN Antisepsis Testing;
•Instant Hi/Low Voltage testing;
•1000 times /one minute Open-Circuit-Testing;
•EMC CISPK22 guard against hertzian waves.

HID Learning Center on Alibaba

1. What is HID?
HID lamp (High-Intensity-Discharge) is the top product of the Metal halide lamp .Unlike Halogen lamps, HID lamps don't have a filament but create light by the arc between two electrodes. There are distinctive metals contained in the arc tube: high-pressure Xenon (99.99%), mercur and metal halide. When starting voltage is applied to the electrodes from the ballast or igniter, an arc is formed between them. The arc activates the Xenon, which in turn ignites the metal halide. The result of this action is the emission of light energy. Due to the high pressures of HID lamp operation, these wavelengths are concentrated in the visible light spectrum. We can get the desired color temperature through changing the pressure of HID lamp or the proportion of the metal halide.

2. Outstanding Features:
A.Super Brightness: The brightness and its luminous flux are increased by 300% as that of the halogen tungsten lamp, so that the lamp can radiate to higher, wider and farther place.
B.Good color temperature: The color temperature is approximately 4300 K –10000k compared to 3000 K for halogen lamp. The common choose is 5500k,which is close to the sunlight and comfortable to our eyes, also benefit for the safe driving indirectly.
C.Low power consumption and high efficiency: The power of Xenon metal halide lamp(35Watt,) for vehicle is only around half of tungsten halogen lamp but emitting 3 times of light.
D.Extremely long life: In practical terms, the life span of the bulb is equal to that of the car. Service life is at least 3000 hours, greatly above total hours of an automobile during normal night, which means that the bulb need only be replaced in exceptional cases.

3. Easy Installation:
Simply replace your factory bulbs with Our Xenon bulbs, plug the bulb to the ballast, and the ballast wire plugs to the factory OEM harness.
