3 Years Aliabab Golden Supplier SM40 Spiral Steel Silo Forming Machine for Storeage

Main technical parameter:

1.  Raw material and thickness:

Ga lvanized steel: 2-4mm

Chromium-nickel steel: 2-3mm, anti-corrosive

Plastic-coated steel: 2-4mm

Carbon steel: 2-4mm

2.  Width of raw material:495mm

3.  Dia meter range of finished silo:2.5-25m

4. Height of finished silo: usually less than 20m

5. Feed speed:3.5-4.5m/min

Application:making circular metallic container

Working process:

Through the 5 forming procedures and 5 kind of steel strip forming merge suturing machine steel strip(thickness:2-4mm;495mm)will be merged forcedly and suture spirally to make cylinder with 4-50m of different diameters.

These steel cylinders are used widely:

1. Material shape (storage): granular material, powder material, liquid material

2. Industry: grain, feed brewing, oil, medicine, food, cement, water treatment

3.Concrete variety(storage): wheat, soybean, maize, sorghum wheat flour, bulk cement fly-ash, sewage, water, chemical syrup

Features of Rx4.0m/m steel strip forming machine

1. Rx4.0m/m steel strip forming merging and suturing machine units is a new type of machine in our company. It is used to produce the Circular Metallic Container, developed from LIPP-SM40 forming machine, improved and holding the same function of LIPP-SM40 forming machine.

2.Rx4.0m/m steel strip forming merging and suturing machine units also have its own advantages, such as convenient to be repaired, avoid installing with different diameter, saving the time and cost of installing. This unit is produced by the Hi-strength Alloy steel, making the operating life longer.
