Three-lamp Dryer Machine
- Dalian
You May Like
-
Drying Equipment for PVC Panel
-
2014 New Design High-Efficiency PVC Pipe Prduction Line
-
2014 New Design High-Efficiency PVC Pipe Prduction Line
-
2014 Pvc Double Tube Production System
-
2014 New Design High-Efficiency Pvc Pipe Manufacturing Machine Price
-
2014 New Design High-Efficiency PVC Pipe Prduction Line/PVC Pipe Machine
Product Details
| Place of Origin | Liaoning, China | Brand Name | JZ | |
| Model Number | KB600,1000,1300 |
Product Description
Specifications
three-lamp dryer machineUsage:drying after UV painting
Feeding speed:5-30m/min
Width:600mm,1000mm,1300mm
Air blower power:0
three-lamp dryer machine
Application Scope:
After surface coating,it is used for drying plastic products ,such as PVC ceiling panel. Also it can be widely used for plywood, wooden floor, laminated floor, plastic product, leather and metal parts!
Specification:
1.Size: 3000mm length×1100mm width×1600mm height
Weight:400kg
2.It can adjust heat emission for three groups of ultraviolet lamp separately, also control them individually. The height
for three lamp brackets, 3 reflective lampshades and 3 ultraviolet rays lampshade with 800mm length and 5kw power are adjusted by aluminum alloy .
3. 3 sets of 550W centrifugal blower with negative pressure adsorption, each of them is controlled separately.
4. 3 sets of 5kw autotransformer is adopted.
5. Specialized galvanized pipe is used on transmission system.
6. Entrance position height is 100mm.
| Model | Processing Width | Transportation Power | Tube Power | Fan Power | Inflow Aperture | Machine Weight | Gross Power | Machine Size | Feeding Speed |
| KB-600 | 600mm | 0.75kw | 5.6kw*3 | 0.75kw*3 | Φ200mm*240*3 | 200kg | 19.6kw | 3000*1000*1800mm | 5-30m/min |
| KB-1000 | 1000mm | 0.75kw | 8kw*3 | 0.75kw*3 | Φ200mm*240*3 | 400kg | 27kw | 3000*1400*1800mm | 5-30m/min |
| KB-1300 | 1300mm | 1.5kw | 9.7kw*3 | 0.75kw*3 | Φ200mm*240*3 | 600kg | 32.9kw | 3000*1700*1800mm | 5-30m/min |
Any question, please feel free to contact us !
