1kv Heatshrink Busbar Insulation Tube
- shenzhen

You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | DICORE | |
| Model Number | HBBT | Type | Heat Shrinkable | |
| Material | PE |
Product Description
Specifications
busbar insulation tube1. ROHS, 1KV,10KV,20KV,35KV
2. 20mm to 250mm diameter
3. Alternative for raychem BBIT/BBTM/LVIT
1kv Heatshrink busbar insulation tube
Model  | HBBT  |
Material  | PE material  |
Type  | 1kv, 10kv, 20kv, 35kv  |
Tubing diameter  | 20mm to 250mm  |
Standard color  | Red, green, yellow and black  |
Operating temperature range  | -55°C to 125°C  |
Shrink temp  | 115°C  |
Insulation and protect bus bar  |
Property:
1KV
SIZE (mm)  | As Supplied(mm)  | After Recovery(mm)  | Packing (m/roll)  | |
I. D.  | I. D. (max)  | W. T.  | ||
30  | 31.5±1.0  | 15.0  | 1.0±0.15  | 50  |
35  | 36.5±1.0  | 17.5  | 1.0±0.15  | 50  |
40  | 41.5±1.0  | 20.0  | 1.0±0.15  | 50  |
50  | ≥50  | 25.0  | 1.1±0.15  | 25  |
60  | ≥60  | 30.0  | 1.2±0.15  | 25  |
10kv, 20kv
SIZE (mm)  | As Supplied(mm)  | After Recovery(mm)  | Packing (m/roll)  | |
I. D.  | I. D. (max)  | W. T.  | ||
15  | ≥15  | 6.0  | 2.5±0.20  | 25  |
20  | ≥20  | 8.0  | 2.5±0.20  | 25  |
25  | ≥25  | 10.0  | 2.5±0.20  | 25  |
30  | ≥30  | 12.0  | 2.5±0.20  | 25  |
40  | ≥40  | 16.0  | 2.8±0.30  | 25  |
50  | ≥50  | 20.0  | 2.8±0.30  | 25  |
65  | ≥65  | 26.0  | 2.8±0.30  | 25  |
75  | ≥75  | 30.0  | 2.8±0.30  | 25  |
85  | ≥85  | 34.0  | 2.8±0.30  | 25  |
100  | ≥100  | 40.0  | 2.8±0.30  | 25  |
120  | ≥120  | 48.0  | 2.8±0.30  | 25  |
150  | ≥150  | 60.0  | 2.8±0.30  | 25  |
180  | ≥180  | 72.0  | 2.8±0.30  | 25  |
210  | ≥210  | 84.0  | 2.8±0.30  | 20  |
230  | ≥230  | 92.0  | 2.8±0.30  | 20  |
250  | ≥250  | 100  | 2.8±0.30  | 20  |
300  | ≥300  | 120  | 2.8±0.30  | 15  |
35kv
