Small Granular Vibrating Filling Machine

FOB Price

US$ 1,500 - 50,000 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Food
Packaging Type	Cans	Packaging Material	Wood
Automatic Grade	Semi-Automatic	Driven Type	Electric
Power	1KW	Place of Origin	Shanghai, China
Brand Name	TOPSPACK	Model Number	TP-GF-A12

Product Description

Specifications

1.Sold to many countries
2.High performance and low price
3.Easy operated
4.High efficiency,high accuracy

Description:

The vibrating filling packaging machine can do measuring and filling work. It’ suitable for the fluidic granular materials, such as rice, sugar, monosodium glutamate, solid drink, glucose, chicken essence, washing powder or expanded granular materials.

Technical Parameter:

Metering Mode		Vibration feed-in & weighing feedback
Packaging Weight:		50-2000g
Packaging Accuracy		≤+/-3g
Packaging Rate		50-300g: ≥25bags/min
		300-1000g: ≥20bags/min
		1000-1500g: ≥15bags/min
		1500-2000g: ≥10bags/min
Power Supply		1P 220V 50HZ~60HZ
Total Power		1000W
Hopper Volume		55L
Total Weight		250Kg
Overall Dimensions		650X680x1800mm
Operation Interface	PLC control, colored touch screen

Characteristics:

Two-independence of the weighing cabinet to weigh: less vulnerable by outside influence, with separate bags, work fast.
Feeder-adjust automatically according the proportion of the material to ensure high-precision and high fast.
Independent single weight sensor: stable performance, high sensitive.
Time can be set to memory the current number of the packing, easy to transfer and timely feedback the rate of qualified products.
Chinese and English interface, time can be set to cooperate with the action, easy to operate.
With calibration procedures: equipped with poise and calibration hooks, adjusted at anytime, it’s very useful the weight drift in long time no using.
Weighing cabinet is sealed by glass, equipped with the dust collector, easy to collect the dust and protect the environment of the workshop.
The weighing cabinet use the linked way, it can be disassembled directly and easy to clean.

Main configure list :

Parts Name	Main Configure
Vibrating feeder	4 pieces
motor	Wanxin Brand from Taiwan
Weighing parts	Hengzhou Electronic or Taida PLC (optional)
Colored PLC touch screen	Weilun Brand from Taiwan, 5.7inch
Electronic controlled parts	Xizi from Hangzhou and others
Optical Sensor	Autonics from Korea
Weighing sensor	Keli (according to customers needs)
Machine material	Stainless steel 304 except for electric controlled parts and conveyor parts
