Home > Products > Yokohama Rubber Fender > Inflatable ship fender,Yokohama type fender
Inflatable ship fender,Yokohama type fender
- Qingdao
- T/T
You May Like
-
small medium large pneumatic rubber fender Yokohama type fender
-
Made in China Floating Dock Yokohama Rubber Fender
-
passed CCS certification pneumatic yokohama rubber fender
-
ISO9001 Quality Standard Certification dock rubber marine YOKOHAMA fender
-
3.0m x 5.0m CCS certification anti-collision equipment yokohama rubber fender
-
High quality of marine yokohama rubber fender with ISO9001 certification
Product Details
| Place of Origin | Shandong, China | Brand Name | Xincheng | |
| Model Number | XC.NO.F536 | Part | Other, Yokohama type fender |
Product Description
Inflatable ship fender,Yokohama type fender
“XINCHENG” Pneumatic Rubber Fender has passed the ISO9001:2008 quality management system certification, each fender is fully comply with ISO17357 and GB/T21482-2008 international production standard.
Fiber layers:
Our equipment :
Pneumatic rubber fender is the advanced anti-collision device for marine application in the world.
Features:
1. Large compression deformation, low reaction force, high energy absorption
2. Good floating performance, can meet the needs of the water level change
3. With compressed air as medium, the collision energy consumption by compressed air power
4. Easy installation and long service life
Structure:
Specification:
Specification D×L m | Initial pneumatic pressure 0.05Mpa | Initial pneumatic pressure 0.08Mpa | ||||
Sphere Weight(KG) | R(KN) | GEA(KJ) | Sphere Weight(KG) | R(KN) | GEA(KJ) | |
0.5×1.0 | 25 | 64 | 6 | 25 | 85 | 8 |
0.6×1.0 | 32 | 74 | 8 | 32 | 98 | 11 |
0.7×1.5 | 50 | 137 | 17 | 50 | 180 | 24 |
1.0×1.5 | 80 | 182 | 32 | 80 | 239 | 45 |
1.0×2.0 | 100 | 257 | 45 | 125 | 338 | 63 |
1.2×2.0 | 120 | 297 | 63 | 165 | 390 | 88 |
1.35×2.5 | 165 | 427 | 102 | 226 | 561 | 142 |
1.5×3.0 | 315 | 579 | 153 | 370 | 761 | 214 |
1.7×3.0 | 405 | 639 | 191 | 436 | 840 | 287 |
2.0×3.5 | 590 | 875 | 308 | 632 | 1150 | 430 |
2.5×4.0 | 1050 | 1381 | 663 | 1110 | 1815 | 925 |
2.5×5.5 | 1333 | 2019 | 943 | 1410 | 2653 | 1317 |
3.0×5.0 | 1880 | 2000 | 1050 | 2155 | 2709 | 1571 |
3.0×6.0 | 2160 | 2488 | 1312 | 2470 | 3292 | 1888 |
3.3×4.5 | 2020 | 1884 | 1175 | 2300 | 2476 | 1640 |
3.3×6.0 | 2300 | 2783 | 1675 | 2600 | 3652 | 2338 |
3.3×6.5 | 2700 | 3015 | 1814 | 3080 | 3961 | 2532 |
3.3×10.6 | 4403 | 5257 | 3067 | 5020 | 6907 | 4281 |
4.5×9.0 | 6554 | 5747 | 4752 | 7470 | 7551 | 6633 |
4.5×12.0 | 8739 | 7984 | 6473 | 9960 | 10490 | 9037 |
Note: The weight and reaction force & Energy absorption tolerance ±10% | ||||||
NOTE:
A, Other sizes besides the above also can be customized.
B, All fenders conform to the latest ISO 17357 directives.
C, All kinds of foam filled marine fenders can be available.
D, Can be delivered in various sizes with chain - vehicle/ aircraft tyre net.
Product Display:
