Ball Mill for the Mineray From Henan
- QingDao/ShangHai Port
- T/T
You May Like
Product Details
| Condition | New | Type | Ball Mill | |
| Motor Type | AC Motor | Power(W) | 18.5KW | |
| Capacity(t/h) | 0.37-2.1 | Place of Origin | Shanghai, China | |
| Brand Name | Donxe | Model Number | MQG900*1800 | |
| Weight | 3.6-4.3T | Certification | ISO2000 | |
| Warranty | 2 years | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specification of Ball Mill:
| Model | balls weight (t) | Rotary Speed (r/min) | The feeding size (mm) | The finalsize (mm) | Capacity (t/h) | Main Motor (kw) | Weight (t) |
| MQG900×1800 | 1.5 | 36-38 | ≤20 | 0.074-0.3 | 0.37-2.1 | 18.5 | 3.6~4.3 |
| MQG900×2400 | 2.1 | 36.4 | ≤20 | 0.074-0.3 | 0.5-2.4 | 18.5 | 4~4.8 |
| MQG900×3000 | 2.7 | 36 | ≤20 | 0.074-0.3 | 0.8-2.5 | 22 | 4.6~5.3 |
| MQG900×3500 | 2.7 | 36 | ≤20 | 0.074-0.3 | 1.1-3.8 | 37 | 5.2~5.8 |
| MQG1200×1200 | 2.4 | 32.1 | ≤25 | 0.074-0.3 | 0.8-1.6 | 30 | 8.5 |
| MQG1200×2400 | 3 | 31.38 | ≤25 | 0.074-0.3 | 1.4-2.8 | 45 | 11.4 |
| MQG1200×3000 | 3.5 | 31.38 | ≤25 | 0.074-0.3 | 1.6-3 | 45 | 12.1 |
| MQG1200×3500 | 5 | 32.4 | ≤25 | 0.074-0.3 | 1.6-3.5 | 55 | 12.7 |
| MQG1200×4500 | 6.5 | 31.8 | ≤25 | 0.074-0.3 | 1.83-3.9 | 55 | 13.1 |
| MQG1500×3000 | 9.7 | 29.2 | ≤25 | 0.074-0.3 | 2.8-9 | 95 | 14.8 |
| MQG1500×3500 | 10.8 | 29.58 | ≤25 | 0.074-0.3 | 3.1-9.7 | 95 | 15.8 |
| MQG1500×4000 | 12 | 29.58 | ≤25 | 0.074-0.3 | 4.8-10 | 110 | 17.9 |
| MQG1500×4500 | 13.5 | 29.58 | ≤25 | 0.074-0.3 | 4.8-11 | 110 | 19.9 |
| MQG1500×5700 | 15 | 30.15 | ≤25 | 0.074-0.3 | 5-16 | 130 | 23.4 |
| MQG1500×6400 | 16 | 30.15 | ≤25 | 0.074-0.3 | 5.4-17.8 | 155 | 25.4 |
| MQG1830×2400 | 10 | 25.4 | ≤25 | 0.074-0.3 | 4-10 | 130 | 23.7 |
| MQG1830×3000 | 14.4 | 26.3 | ≤25 | 0.074-0.3 | 4.5-10.5 | 130 | 26.6 |
Introduction:
Ball Mill is an efficient tool for grinding many materials into fine powder. The Ball Mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine. To use the Ball Mill, the material to be ground is loaded into the Neoprene barrel that contains grinding media. As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours.
Quite simply, the longer the Ball Mill runs, the finer the powder will be. Ultimate particle size depends entirely on how hard the material you're grinding is, and the time how long the Ball Mill runs. Our Ball Mills have been used to grind glass, powder food products, create custom varnishes, make ceramic glaze, powder various chemicals, and make Black Powder.
Picture:
Our company is a high-technology enterprise of Shanghai and achieved CQC ISO9001/2000. We are a professional manufacturer and supplier of mining crusher, industrial grinding mills ,and benefication equipment .
Our company features advanced CAD and computer simulation test system which ensures the quality of design,development,manufacturing,and after-sale services. We can provide crushing,sand-making ,gravity benefication, magentic separation,flotation separation and cyanidation separation lines. What we can provide is not only the equipments, but the professional beneficiation technology according to your reqirements.
Our company has independent import-export right with a special international trade deparment to deal with exporting affair, we have a professional after-sale service faculty to provide considerate and all-around-way service for the customers.
Enterprise idea
Professional team is the core competitiveness of enterprise.
Excellent quality is the life of enterprise.
Customer is the king.
