SS100/100 Building Material Hoist/construction Building Lifter

A.introduction of SS100/100 building material hoist

♦SS100/100 building material hoist is a vertical handling machine dedicated for materials widely applied in building construction, industrial and mining, multi-storey workshop, warehouse, station, wharf, etc. It is convenient, efficient, and secure.

♦SS100/100 is set up with safety multiple protection measures like Floor-selecting and Leveling Device, Elevating Limiter, Rope Protection Device, Parking Safety Device, Bumper, Upper and Lower Height Restrictor, Anti Rope-breaking Equipment, among which, the brake performance and brake slide distance of the Rope Protector are above  national  standards. It is safe, reliable, and harmless to rail-track.
♦There are two accesses for Floor Selecting and Leveling: 1. Manual Control, which is direct control by the operator. 2. Computer Automatic Positioning System (Optional for order), which can easily realize floor-selecting and leveling without manual stop or point car leveling, reducing the difficulty of manipulation, convenient and precise.
♦ SS100/100 adopts Wall-attaching Device instead of Wind Rope, along with self-erection and dismantling unit (Derrick), easy for handling and transportation.
♦ SS100/100 has 2 types: Single-caged and Double-caged, optional for users. The standard sections of Double-caged are 4 pieces of ø76 * 4 seamless steel pipes, which can also be taken as guide rail, while those the Single-caged are 2 ø51 * 4 pipes

B. Eight selling points

1. Monitor control unit

2. Weight limit device

3. Fall protection device

4. Microcomputer speed device

5. GPS fixing system

6. Floor select system

7. Floor calling system

8. Floor stop protection device

C. Advantages of  SS100/100 building material hoist

1. CE, ISO, GOST certificates

2. SC construction elevator have one year guarantee

3. Special made can be accepted

4. Good after sale service.

D. Technical Parameters
