Product Details
| Place of Origin | Beijing, China | Brand Name | Jinfei Tianhong | |
| Model Number | SC200/200 | Usage | Residential Elevators | |
| Drive Type | Other, Rack & Pinion | Elevator Type | Passenger Elevators |
Product Description
Specifications
construction lift1. Manufacturer
2. MOQ: 1 set
3. Quality guarantee: 1 year
4. Good after-sale service
construction lift
1. building hoist, construction passenger hoist, construction tower hoist
2. internationally approved quality
3. over 10 years' expertise
4. cutting-edge technologies
SC200/200 Building Hoist adopted computer aided design. Comparing with traditional building hoists,
it is attractive, light, easy to handle, secure, applicable, and popular. Depending on special needs of regular or irregular sections,
the lifting capacity can reach up to 1~2 tons, and the running speed can reach 28~38m/min. Moreover,
VVVF speed regulation and PLC enable 0~68 limitless speed, automatic layer selecting and leveling as required.
SC200/200 Building Hoist is excellent in technical performance, more secure in operating mechanism, and more compact in structure.
Model: Cage Capacity :
SC100 (Single cage) 1T
SC100/100 (Double cage) 1T*1T
SC200 (Single cage) 2T
SC200/200 (Double cage) 2T* 2T
- Capacity – 1T, 1.5T, 2T, 3T & 4T
- Cage
- Single
- Double
- Cage Dimension
- Standard - 3 X 1.4 X 2.4 Mtrs.
- Customized upto 4.5 x 2.5 x 3.5 Mtrs.
Name | Unit | SC100 | SC100/100 | SC200 | SC200/200 |
Rating loading capacity | Kg | 1000 | 2×1000 | 2000 | 2×2000 |
Passenger number | Person | 12 | 2×12 | 16 | 2×16 |
Rating rising rate | M/min | 36 | 36 | 36 | 36 |
Max. promoting height | M | 200 | 200 | 200 | 200 |
Motor power | KW | 2×11 | 2×2×11 | 3×11 | 2×3×11 |
Voltage | V/ HZ | 380/50 | 380/50 | 380/50 | 380/50 |
Cage size | M | 3*1.3*2.5 | 3*1.3*2.5 | 3*1.5*2.5 | 3*1.5*2.5 |
650 mast section weight | Kg | 128 | 150 | 128 | 150 |
650 mast section length (painted) | M | 0.65×0.65 ×1.508 | 0.65×0.65 ×1.508 | 0.65×0.65 ×1.508 | 0.65×0.65 ×1.508 |
Steeve rating rising weight | Kg | 200 | 200 | 200 | 200 |
Containers for Shipment | pcs | 1*40’HQ | 1*40’HQ | 1*40’HQ | 1*40’HQ |
We can make 30m,50m,60m,70m,72m to 90m.
Main parts as below:
A: Cage with wheelhouse
B:safety device in cage
Breaker of high quality
Wonderful power motor
mast section with good material
Certification of CE,GOST,CCC and so on
