Cherry picker with high quality and affordable price
- 6000 Set / Sets per Month
- Tianjin
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Beijing, China | |
| Brand Name | Jinfei Tianhong | Model Number | ZLP suspending platform | |
| Rated Loading Capacity(kg) | 800Kg | Hoisting Speed | 8-10m/min | |
| Max Lifting Height | 300 m | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
ZLP series suspended platform with load capacity 800kg
Advantages of portable stage platform
1) The length of platform can be adjusted.
2) Special platforms can be designed and made according to your specific requirements.
3) The platform's materials can be chosen:
a. Aluminum alloy
b. Steel with spraying
c. Steel with galvanizing
4) The working height can be adjusted.
5) The voltage and frequency can be adjusted to different countries' standard.(220V-440V / 50Hz-60Hz)
6) Simple & flexible, easy to shift & operate, safe & reliable.
7) CE, Gost, ISO9000/2001 Certification.
8) 12 months quality warranty, and good after-sales service.
9) Fast delivery and efficient service.
10) Manufacturer, factory.
Technical Parameters of building clean cradle
| Model | ZLP500 (5m) | ZLP630 (6m) | ZLP800 (7.5m) | ZLP1000 (7.5m) | ||
| Rated load | 500Kg | 630Kg | 800Kg | 1000Kg | ||
| Lifting speed | 8-10m/min | 8-10m/min | 8-10m/min | 8-10m/min | ||
Platform Dimension L×W×H(mm) Spray plastics corrosion-resistant | 5000(2+3m) ×720×1300 | 6000(1+2+3m) ×720×1300 | 7500(2.5m*3) ×720×1300 | 7500(3*2.5) ×720×1300 | ||
| Lifting Height | 100 m | 100 m | 100 m | 100 m | ||
| Cable | 100 m | 100 m | 100 m | 100 m | ||
| Steel rope (specially-made) | 8.3mm | 8.3mm | 9.1mm | 8.6mm | ||
| Hoist | Electric motor | Power | 1.5KW*2 | 1.5KW*2 | 1.8KW*2 | 2.2 KW*2 |
| Voltage | 380V/50HZ | 380V | 380V | 380V/50HZ | ||
| Safety lock | Permission force of impact | 30KN | 30KN | 30KN | 30KN | |
| Locking Cable Angle | 3°~8° | 3°~8° | 3°~8° | 3°~8° | ||
| Suspension mechanism(Galvanized ) | Front beam overhang | 1.3~1.5m | 1.3~1.5m | 1.3~1.5m | 1.3~.1.5m | |
Support adjustable height | 1.44~2.14m | 1.44~2.14m | 1.44~2.14m | 1.44~2.14m | ||
| Counterweight | 800KG | 800kg | 1000kg | 1200KG | ||
| 20’ft container | 10 sets | 9sets | 8sets | 8 sets | ||
| 40’ft container | 15sets | 14sets | 13sets | 13 sets | ||
You know the price of portable stage platform depend on its parameters.
Can you write to us its material of platform,loading capacity and counter weight when you choose the platform?
And now I hope these picture can help you:
NO.1 Material:
NO.2 TYPE OF PLATFORM
NO.3 MAIN PARTS OF Suspended Working Platforms
NO.4 Suspension Mechanism OF suspended platform
NO.5 Material of Counter weight
NO.6 Package of products
NO.7 Shipping
