Lilliput 9.7 Inch FPV Fatshark HDMI Monitor With Wireless Receiver

Specifications

969AFPV-5.8GH (with BNC interfaces)

Multiple power support, makes outdoor photography more convenient and practical.
No "blue screen" problem when the signal gets weak, flying much further and never lose image.
Sunlight readable with ultra brightness & definition screen.
5.8GHz Wireless AV Receiver
Built-in AV receiver support PAL / NTSC switch automatically, anti-black, anti-blue, anti-flash. aerial camera connection.
Not affect by 2.4GHz R/C Radios
High capacity rechargeable Li-ion battery, make power cables free.
Small, light weight, durable.

5.8GHz 8 Channel AV  receiver
Video Format :NTSC/PAL
Channel Frequency
CH1  5705  ---  MHz
CH2  5685  ---  MHz
CH3  5665  ---  MHz
CH4  5645  ---  MHz
CH5  5885  ---  MHz
CH6  5905  ---  MHz
CH7  5925  ---  MHz
CH8  5945  ---  MHz

Wireless Receiver Channel (Mhz) (5705 5685 5665 5645 5885 5905 5925 5945 and FATSHARK: 5740 5760 5780 5800 5820 5840 5860 ,choose 1 of them, We would send 5705 5685 5665 5645 5885 5905 5925 5945  as default, if you need other option, please contact us when you order. )

Wide viewing angles,
High resolution: 1024×768,
High brightness: 420cd/M2,
High contrast: 900:1,
Dual HDMI input,
USB 5V output for charging,
Wide voltage: DC 7-24V,
TALLY interface with indicating light,
Gimbal bracket for installation,
Comply with IP52 standard.

Advanced Functions:
Peaking Filter, False Colors, Histogram, Exposure, Camera, Center Marker, Pixel-to-Pixel, Color Bar, Screen Marker, Aspect Ratio, Check Field, Underscan/Overscan, Freeze Input, H/V Delay, 8x Zoom, Picture-in-Picture.

Panel Size: 9.7"
Physical Resolution: 1024×768
Aspect Ratio: 4:3
Brightness: 420cd/m2
Contrast: 900:1
Viewing Angle: 178°/ 178°(H/V)
Input Signal: HDMI×2, YPbPr,  5.8gHz wireless AV , TALLY
Output Signal: YPbPr,   5.8gHz wireless AV , USB(5V)
Audio: Speaker×1(built-in), Ear Phone Slot×1(built-in)
Current: 560mA
Input Voltage: DC 7-24V(XLR Connector)
Battery Plate: V-mount, Anton Bauer mount, F-970, QM91D, DU21, LP-E6
Power Consumption: ≤18W
Operating Temperature: -20°C ~ 60°C
Storage Temperature: -30°C ~ 70°C
Dimension(LWD): 246×224×31mm/167.5mm(with cover open)
Weight: 1068g / 1388g (with cover)

Accessories:
1. Flexible folding sun shade cover: 1piece
2. Battery plate bracket: 1piece
3. Battery plate (F-970, QM91D, DU21 or LP-E6): 2pieces
4. HDMI A/A cable: 1piece
5. DC 12V power adapter (XLR connector): 1piece
6. TALLY connector: 1piece
7. Manual: 1copy
8. Gimbal bracket : 1piece
