Home > Products > Others > Temperature Range From -65~-60 Degree Manufacturing Cooling and Heating Machine

Temperature Range From -65~-60 Degree Manufacturing Cooling and Heating Machine

FOB Price

US$ 1,000 - 500,000 / Set

1 Set(Min. Order)

Port Shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	LNEYA		Model Number	GX-6528N
Place of Origin	Jiangsu, China

Product Description

Test chamber GX-6528N

Overview:

Microcomputer control, cascade temperature controller, digital temperature display, the regulation of unit 0.1℃, inside the temperature range -20 ℃ ~ -125 ℃ adjustable.

Multi-safety protection, more reliable operation.

France TECUMSEH compressor, Germany DANFOSS compressor, EMERSON compressor, automatic cascade refrigeration technology.

With self-diagnosis function, freezer overload protection, high pressure switches, overload relays, thermal protection device and other security functions, and fully guarantee the use of safety.

Three sealed mold layer of insulation, Extra-thick high-density polyurethane foam insulation layer, the effect of good insulation; Inline vacuum insulation panels.

Human design, more convenient and flexible.

Suitable for mechanical producing plant use.

Large condenser design, fully guaranteed plant environment cooling effect.

Wide volume ratio design, large load capacity design.

Can be set to open compressors and compressor off temperature.

Fault alarm (over-temperature alarm, sensor alarm, high alarm, overheat alarm compressor.

Delay boot protection.

So grounding components safely.

7inch touch screen display, clear display inside temperature and the desire temperature; can set the over temperature alarm and the inside temperature, fault prompt functions.

Non-standard sizes can be customized, Ultra-low temperature freezer (can be produced within -100℃ 100 cubic).

Optional equipments: PLC controller, temperature recorder etc.

Can be used in touch screen, screen frozen degumming and disassembly

Application:

It is mainly used in industrial refrigerating treatment, so that the matrix of the metal structure to generate a uniform, fine and dispersed precipitation. The precipitation of carbide will improve the abrasion resistance, friction performance and increase hardness of metal. The carbide is the ideal alternative to liquid nitrogen.

For the copper sleeve and bearings contracting, it is widely used in precise mechanical assembly. Applied to large scale equipment(cars, large engineering machineries, aircraft component, Aerospace equipment parts, Military equipment parts etc.) lower temperature test.

Technical Parameters:

Model	GX-6528N	GX-6550N	GX-6580N	GY-6528N	GY-6550N	GY-6580N	GY-65A16N
volume	280L	500L	800L	280L	500L	800L	1600L
Inner dimension	610600760	800735850	10008001000	800600600	1200650650	1350800750	2000900900
Type	(Vertical)			(Chest/Horizontal)
Capacibility carrying	150KG	220KG	300KG	150KG	220KG	300KG	650KG
	Designed bearing capacity is two times of the standard one, (refrigeration system is designed according to the standard capacity, when target artifact weight is greater than the standard capacity, the cooling rate will decrease)
Temp. range	-65℃~60℃	-65℃~60℃	-65℃~60℃	-65℃~60℃	-65℃~60℃	-65℃~60℃	-65℃~60℃
Cooling capacity at -60℃	1kw	1.5kw	2.5kw	1kw	1.5kw	2.5kw	4kw
Temp. accuracy	±2℃	±2℃	±2℃	±2℃	±2℃	±2℃	±2℃
Heating power	2kw	3kw	5kw	2kw	3kw	5kw	8kw
	Nickel-chromium alloy electric heating heater, the controller has double safety protection, with independent temperature limiter protection.
Cooling rate	(ambient temperature of 25 degrees, no-load, from 60 degrees to -60 degrees about 1 hour).;cooling rate will be a little different for temperature changes.
Controller	ASET multifunctional controller
Operation panel	7-inch color touch screen , display set temperature, measured temperature.
Temp. record	Temperature curve and fault record , U-disk data export, excel format.
Inside circulating air	1650 m³/h	2100 m³/h	2750 m³/h	2100 m³/h	2750 m³/h	3500 m³/h	6000 m³/h
	When it is open, the internal circulation fan automatically turns off. The touch screen displays open state.
Compressor	Emerson Copeland , adopt cascade refrigeration technology
Intermediate heat exchanger	KAORI Plate heat exchanger
Dry filter	Emerson
Expansion valve	Electronic expansion valve
Evaporator	Copper-tube with aluminum-fin
Cooling Type	Air-cooled with water-cooled auxiliary functions (Ensure good cooling capacity when temp. above 30 degree)
Means of insulation	Polyurethane foam insulation, thermal insulation layer 125 mm, with embedded FIR boards
Safety Protection	Self-diagnosis function;Phase sequence phase failure protection; leakage protector; cooling unit overload protection; high and low pressure switch, overload relay, thermal protection device, high temperature protection and temperature fault protection.
Case material	Outside is cold rolled steel painting, internal is SUS304 wire drawing board.
Refrigerant	R404A R23
Dimension	115011501850	135013001850	155013002100	220011501150	270012001200	290013001250	370014001350
Power 380V 50HZ	5.5KW MAX	7.5KW MAX	13.5KW MAX	5.5KW MAX	7.5KW MAX	13.5KW MAX	19KW MAX
Weight	380kg	480kg	650kg	385kg	485kg	650kg	780kg
Optional	High temperature reaches 150degree and temperature accuracy is ±0.5degree;the input power will be changed(When select this model, the thickness of thermal insulation layer will be 150mm,thermal insulation material will be silicate and vacuum plate)
Optional	Closed circulating oil heating system, no direct electric heating element inside the box, suitable for flammable products test
Optional	Temp. accuracy ±0.5℃
Optional	Cooling and heating with program controlled, meet cold treatment process requirements(can set 5 programs, each program can edit 45 steps.)
Optional	Interior door, reduce cooling capacity lost when pick small workpieces (temperature below 60 degree optional)
Optional	Outside SUS304 wire drawing board case
Optional	Diameter 50mm cable hole
Optional	Electric heating vacuum glass observation window (with lighting) 200mm*300mm
Optional	Low temperature automatic defrost (can be once per hour or use manual button to defrost), ensure it can work at low temperature for long time even the door is open and close frequently)

Model	GX-8028N	GX-8050N	GX-80A10N	GY-8028N	GY-8050N	GY-8080N	GY-80A16N
Volume	280L	500L	1000L	280L	500L	800L	1600L
Inner dimension	610600760	800735850	100010001000	800600600	1200650650	1350800750	2000900900
Type	(Vertical)			(Chest/Horizontal)
Capacibility carrying	150KG	220KG	300KG	150KG	220KG	300KG	650KG
Capacibility carrying	Designed bearing capacity is two times of the standard one, (refrigeration system is designed according to the standard capacity, when target artifact weight is greater than the standard capacity, the cooling rate will decrease)
Temp. range	-80℃~60℃	-80℃~60℃	-80℃~60℃	-80℃~60℃	-80℃~60℃	-80℃~60℃	-80℃~60℃
Cooling capacity at -75℃	1kw	1.5kw	2.5kw	1kw	1.5kw	2.5kw	4kw
Temp. accuracy	±2℃	±2℃	±2℃	±2℃	±2℃	±2℃	±2℃
Heating power	2kw	3kw	5kw	2kw	3kw	5kw	8kw
Heating power	Nickel-chromium alloy electric heating heater, the controller has double safety protection, with independent temperature limiter protection.
Cooling rate	(ambient temperature of 25 degrees, no-load, from 60 degrees to -60 degrees about 1 hour).;cooling rate will be a little different for temperature changes.
Controller	ASET multifunctional controller
Operation panel	7-inch color touch screen , display set temperature, measured temperature.
Temp. record	Temperature curve and fault record , U-disk data export, excel format.
Inside circulating air	1650 m³/h	2100 m³/h	2750 m³/h	2100 m³/h	2750 m³/h	3500 m³/h	6000 m³/h
Inside circulating air	When it is open, the internal circulation fan automatically turns off. The touch screen displays open state.
Compressor	Emerson Copeland , adopt cascade refrigeration technology
Intermediate heat exchanger	KAORI Plate heat exchanger
Dry filter	Emerson
Expansion valve	Electronic expansion valve
Evaporator	Copper-tube with aluminum-fin
Cooling Type	Air-cooled with water-cooled auxiliary functions (Ensure good cooling capacity when temp. above 30 degree)
Means of insulation	Polyurethane foam insulation, thermal insulation layer 125 mm, with embedded FIR boards
Safety Protection	Self-diagnosis function;Phase sequence phase failure protection; leakage protector; cooling unit overload protection; high and low pressure switch, overload relay, thermal protection device, high temperature protection and temperature fault protection.
Case material	Outside is cold rolled steel painting, internal is SUS304 wire drawing board.
Refrigerant	R404A R23
Dimension	115011501850	135013001850	155015002100	220011501150	270012001200	290013001250	370014001350
Power 380V 50HZ	7KW MAX	11.5KW MAX	15KW MAX	7KW MAX	11.5KW MAX	15KW MAX	21KW MAX
Weight	400kg	500kg	690kg	415kg	525kg	710kg	840kg
Optional	High temperature reaches 150℃ and temperature accuracy is ±0.5℃;the input power will be changed(When select this model, the thickness of thermal insulation layer will be 150mm,thermal insulation material will be silicate and vacuum plate)
Optional	Closed circulating oil heating system, no direct electric heating element inside the box, suitable for flammable products test
Optional	Temp. accuracy ±0.5℃
Optional	Cooling and heating with program controlled, meet cold treatment process requirements(can set 5 programs, each program can edit 45 steps.)
Optional	Interior door, reduce cooling capacity lost when pick small workpieces (temperature below 60 degree optional)
Optional	Outside SUS304 wire drawing board case
Optional	Diameter 50mm cable hole
Optional	Electric heating vacuum glass observation window (with lighting) 200mm*300mm
Optional	Low temperature automatic defrost (can be once per hour or use manual button to defrost), ensure it can work at low temperature for long time even the door is open and close frequently)

Model	GX-A028N	GX-A050N	GX-A0A10N	GY-A028N	GY-A050N	GY-A080N	GY-A0A16N
Volume	280L	500L	1000L	280L	500L	800L	1600L
Inner dimension	610600760	800735850	100010001000	800600600	1200650650	1350800750	2000900900
Type	(Vertical)			(Chest/Horizontal)
Capacibility carrying	150KG	220KG	300KG	150KG	220KG	300KG	650KG
Capacibility carrying	Designed bearing capacity is two times of the standard one, (refrigeration system is designed according to the standard capacity, when target artifact weight is greater than the standard capacity, the cooling rate will decrease)
Temp. range	-100℃~60℃	-100℃~60℃	-100℃~60℃	-100℃~60℃	-100℃~60℃	-100℃~60℃	-100℃~60℃
Cooling capacity at -90℃	0.7kw	1 kw	2 kw	0.7kw	1 kw	2 kw	3kw
Temp. accuracy	±2℃	±2℃	±2℃	±2℃	±2℃	±2℃	±2℃
Heating power	2kw	3kw	5kw	2kw	3kw	5kw	8kw
Heating power	Nickel-chromium alloy electric heating heater, the controller has double safety protection, with independent temperature limiter protection.
Cooling rate	(Ambient temperature of 25℃, no-load, from 60 ℃s to -95 ℃ about 1 hour).;cooling rate will be a little different for temperature changes.
Controller	ASET multifunctional controller
Operation panel	7-inch color touch screen , display set temperature, measured temperature.
Temp. record	Temperature curve and fault record , U-disk data export, excel format.
Inside circulating air	1650 m³/h	2100 m³/h	2750 m³/h	2100 m³/h	2750 m³/h	3500 m³/h	6000 m³/h
Inside circulating air	When it is open, the internal circulation fan automatically turns off. The touch screen displays open state.
Compressor	Emerson Copeland , adopt cascade refrigeration technology
Intermediate heat exchanger	KAORI Plate heat exchanger
Dry filter	Emerson
Expansion valve	Electronic expansion valve
Evaporator	Copper-tube with aluminum-fin
Cooling Type	Air-cooled with water-cooled auxiliary functions (Ensure good cooling capacity when temp. above 30℃)
Means of insulation	Polyurethane foam insulation, thermal insulation layer 125 mm, with embedded FIR boards
Safety Protection	Self-diagnosis function;Phase sequence phase failure protection; leakage protector; cooling unit overload protection; high and low pressure switch, overload relay, thermal protection device, high temperature protection and temperature fault protection.
Case material	Outside is cold rolled steel painting, internal is SUS304 wire drawing board.
Refrigerant	R404A R23 R14
Dimension	115011501850	135013001850	155015002100	220011501150	270012001200	290013001250	370014001350
Power 380V 50HZ	9KW MAX	13.5KW MAX	18KW MAX	12KW MAX	16.5KW MAX	20KW MAX	30KW MAX
Weight	470kg	580kg	750kg	495kg	625kg	810kg	940kg
Optional	High temperature reaches 150℃ and temperature accuracy is ±0.5℃;the input power will be changed(When select this model, the thickness of thermal insulation layer will be 150mm,thermal insulation material will be silicate and vacuum plate)
Optional	Temp. accuracy ±0.5℃
Optional	Cooling and heating with program controlled, meet cold treatment process requirements(can set 5 programs, each program can edit 45 steps.)
Optional	Interior door, reduce cooling capacity lost when pick small workpieces (temperature below 60℃ optional)
Optional	Outside SUS304 wire drawing board case
Optional	Diameter 50mm cable hole
Optional	Electric heating vacuum glass observation window (with lighting) 200mm*300mm
Optional	Low temperature automatic defrost (can be once per hour or use manual button to defrost), ensure it can work at low temperature for long time even the door is open and close frequently)

Gerating treatment equipment is produced specially, please provide us the following information:

1. Maximum Loading.

2. Liner Size:L/W/H

3. Full load cooling to the time of the target value.

FAQ

2015 Corning Reactor and its Ancillary Equipment Technology Exchange Meeting
