Air Cooling Chiller With Only Cooling System
- Shanghai
You May Like
-
Temperature Range From -65~-60 Degree Manufacturing Cooling and Heating Machine
-
Minus15 to 30 Degree Small Lab Chiller
-
Industrial Using Constant Temperature Control Refrigeration Unit
-
Minus 10 to 200 Degree Laboratory Refrigeration Equipment
-
-50~250 Degree Laboratory Water Cool Chiller
-
-90~ -130 Degree Touch Screen Degumming Freezer
Product Details
| Type | Air-Cooled | Place of Origin | Jiangsu, China | |
| Brand Name | LNEYA | Model Number | LX-0700N | |
| Cooling Capability(kw) | 1.5~4KW | Voltage | 380V | |
| Weight | 180kg | Certification | CE | |
| Warranty | One Year | After-sales Service Provided | Overseas third-party support available |
Product Description
Chiller temperature range from -25 up to 30 degree LX-0700N mini chiller cooling system
Model | LX-0250N | LX-0400N | LX-0700N | LX-1000N | LX-1450N | LX-2000N | |
Medium Temperature Range | -15℃~30℃ | -25℃~30℃ | -25℃~30℃ | -25℃~30℃ | -25℃~30℃ | -25℃~30℃ | |
Temp. control | ASET multifunctional controller | ||||||
Temp. control optional | Heat-conducting medium outlet temp. control | ||||||
communication protocol | MODBUS RTU Protocol, RS 485 Interface | ||||||
Temp. feedback | Heat-conducting medium temperature feedback PT100 | ||||||
Cooling capacity | 0℃ | 1.5kW | 2.4kW | 4kW | 7.5kW | 10kW | 15.5kW |
-10℃ | 1kW | 1.5kW | 2.7kW | 6.3kW | 8kW | 12kW | |
-20℃ | 0.55kW | 0.8kW | 1.5kW | 3.5kW | 5kW | 7.3kW | |
Circulation pump | Max20L/min 0.7BAR | Max20L/min 0.7BAR | Max35L/min 1BAR | Max50L/min 1BAR | Max75L/min 1BAR | Max75L/min 1BAR | |
capacity of liquid storage | 15L | 25L | 30L | 35L | 45L | 60L | |
Compressor | Tecumseh | Tecumseh | Copeland | Copeland | Copeland | Copeland | |
Evaporator | copper tube | ||||||
Operating controller | 7-inch color touch screen, temperature curve record, excel-format export | ||||||
Security protection | Self-diagnosis function; freezer overload protection; high pressure switch; overload relay, thermal protection device etc. security protection function. | ||||||
Refrigerants | R-404A | ||||||
Connection size | DN-15 | DN20 | DN20 | DN20 | DN20 | DN-20 | |
Product size (air-cooled) | 400*600*1050 | 400*600*1150 | 500*680*1350 | 550*680*1450 | 620*680*1550 | 750*750*1750 | |
Weight (air-cooled) | 115KG | 145kg | 180kg | 225kg | 290kg | 340kg | |
Power | AC220V 50HZ 1.5kW (max) | AC220V 50HZ 2.2kW (max) | AC220V50HZ 3.5kW (max) | AC380V 50HZ 4kW (max) | AC380V 50HZ 5kW (max) | AC380V50HZ 6.5kW (max) | |
Material | Cold rolled steel | ||||||
Optional | Match 7-inch color touch screen controller, temperature curve record, data export to excel format. | ||||||
Optional | Circulation Pump Optional: 35L/min 2.5bar 50L/min 2.5bar 110L/min 2.5bar | ||||||
Optional | SUS304 material | ||||||
Optional | Pressure max. 10 bar circulating pump | ||||||
Optional Power | 220V 60HZ three-phases, 440V~480V 60HZ three-phases | ||||||
Remark | Can make the bigger capacity of water storage as required. | ||||||
2015 Corning Reactor and its Ancillary Equipment Technology Exchange Meeting
- Development history
In 2006 Start production of refrigeration and heating system equipments.
In 2007 Developed the first generation of refrigeration and heating thermostat and establish the LNEYA CO., LTD.
In 2008 Developed the first generation of refrigeration and dynamic temperature control system.
In 2009 Developed the second generation of refrigeration and heating thermostat.
In 2010 Established WUXI GUANYA REFRIGERATION TECHNOLOGY CO., LTD.
Developed the second generation of refrigeration and heating dynamic temperature control system.
Developed the refrigeration and heating dynamic temperature control system & low temperature freezer for industry use.
In 2011 Developed new technology with single compressor having multiple circulation systems (can reach to -80 degree with single compressor)
Upgraded the second generation of refrigeration and heating dynamic temperature control system.
In 2012 Single compressor having multiple circulation systems is applied in production of SUNDI-4, SUNDI-5, SUNDI-6, and SUNDI-7, SUNDI-8 and LT series.
Upgraded the second generation of refrigeration and heating dynamic temperature control system for the second time and developing the third generation of refrigeration and heating dynamic temperature control system.
In 2013 Developed new product one operating multi refrigeration and heating temperature control system(the third generation of refrigeration and heating dynamic temperature control system).At the same time testing the large capacity of ultra-low temperature freezer.
In 2014 Developed with large capacity of ultra-low temperature freezer which used for industrial production,new goods will be research.And it will be launched in the market soon........
